Chapter 2
Publication
1771-6.5.88 – July 1997
Command Word/Bit
Descriptions
Command blocks provide the parameters that control machine
operation. Command blocks are transferred from the PLC processor
to the QDC module by block transfer write (BTW) instructions in
software ladder logic.
Acronym:
Block ID
Binary: Decimal: Description: Page:
CLC 00011011 27 Clamp and Eject ERC Values Block 2-7
CPC 00000111 7 Clamp Close Profile Block 2-8
DYC 00011001 25 Dynamic Command Block 2-13
EAC 00010110 22 Ejector Advance Configuration Block 2-26
EPC 00011000 24 Ejector Profile Block 2-30
ERC 00010111 23 Ejector Retract Configuration Block 2-37
FCC 00000011 3 First Clamp Close Configuration Block 2-40
FOC 00010001 17 First Clamp Open Configuration Block 2-44
HDC 00001011 11 Hold Configuration Block 2-47
HPC 00001100 12 Pack/Hold Profile Block 2-50
INC 00001000 8 Injection Configuration Block 2-53
IPC 00001001 9 Injection Profile Block 2-56
JGC 00000010 2 Jog Configuration Block 2-62
LPC 00000110 6 Clamp Low Press Close Configuration Block 2-65
MCC 00000001 1 Module Configuration Command Block 2-68
OPC 00010101 21 Clamp Open Profile Block 2-74
OSC 00010100 20 Clamp Open Slow Configuration Block 2-79
PKC 00001010 10 Pack Configuration Block 2-82
PLC 00001110 14 Plastication Configuration Block 2-85
PPC 00001111 15 Plastication Profile Block 2-88
PRC 00001101 13 Pre-Decompression Configuration Block 2-91
PSC 00010000 16 Post-Decompression Configuration Block 2-93
PTC 00011100 28 Process Trace Configuration Block 2-95
RLC 00011010 26 Inject ERC Values Block 2-96
SCC 00000100 4 Second Clamp Close Configuration Block 2-97
SOC 00010010 18 Second Clamp Open Configuration Block 2-101
TCC 00000101 5 Third Clamp Close Configuration Block 2-104
TOC 00010011 19 Third Clamp Open Configuration Block 2-107
Refer to chapter 3 for the word/bit descriptions of status blocks.
Alphabetical List of
Command Blocks and
Block ID Codes
