1–47Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
RLS15 N44:551 Injection segment 7
RLS16 N44:552 Injection segment 8
RLS17 N44:553 Injection segment 9
RLS18 N44:554 Injection segment 10
RLS19 N44:555 Injection segment 11
ERC Actuals from Pack Profile
RLS20 N44:556 Pack segment 1
RLS21 N44:557 Pack segment 2
RLS22 N44:558 Pack segment 3
RLS23 N44:559 Pack segment 4
RLS24 N44:560 Pack segment 5
ERC Actuals from Hold Profile
RLS25 N44:561 Hold segment 1
RLS26 N44:562 Hold segment 2
RLS27 N44:563 Hold segment 3
RLS28 N44:564 Hold segment 4
RLS29 N44:565 Hold segment 5
ERC Actuals from Plastication Profile
RLS30 N44:566 Plastication segment 1
RLS31 N44:567 Plastication segment 2
RLS32 N44:568 Plastication segment 3
RLS33 N44:569 Plastication segment 4
RLS34 N44:570 Plastication segment 5
RLS35 N44:571 Plastication segment 6
RLS36 N44:572 Plastication segment 7
RLS37 N44:573 Plastication segment 8
RLS38 N44:574 Plastication segment 9
RLS39 N44:575 Plastication segment 10
RLS40 N44:576 Plastication segment 11
RLS41-64 N44:577-600 RFU
Important: If using Pro-Set 600 and a QDC module configured for
Clamp/Eject mode, this data is found in alternate files B35 and N41.
Word Pro-Set Address Description
Bit-Mapped Status Words
SYS01 B34:0 Block ID 00000001 (lower byte)
SYS01 B34:0 Jog status (upper byte)
SYS02 B34:1 Status of profile execution
SYS03 B34:2 Miscellaneous status
SYS04 B34:3 Status of watchdog timers
SYS05-08 B34:4-7 Status of real-time alarms
SYS09-12 B34:8-11 Status of latched alarms
SYS13-14 B34:12-13 Command errors
SYS15-16 B34:14-15 Status of transferred command blocks
SYS17-18 B34:16-17 Status of last block decoding
SYS19-20 B34:18-19 Programming error alarms
SYS21 B34:20 Status of profile execution
SYS22 B34:21 Status of End of Profile action
SYS23 B34:22 Status of trace data collection in progress
SYS24 B34:23 Status of process trace data collected
SYS - System Status Block
