1–46 Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
Bit-mapped Status Words
PTS19 N132:70 Inject segment 5 start data point
PTS20 N132:71 Inject segment 6 start data point
PTS21 N132:72 Inject segment 7 start data point
PTS22 N132:73 Inject segment 8 start data point
PTS23 N132:74 Inject segment 9 start data point
PTS24 N132:75 Inject segment 10 start data point
PTS25 N132:76 Inject segment 11 start data point
PTS26 N132:77 Pack segment 1 start data point
PTS27 N132:78 Pack segment 2 start data point
PTS28 N132:79 Pack segment 3 start data point
PTS29 N132:80 Pack segment 4 start data point
PTS30 N132:81 Pack segment 5 start data point
PTS31 N132:82 Hold segment 1 start data point
PTS32 N132:83 Hold segment 2 start data point
PTS33 N132:84 Hold segment 3 start data point
PTS34 N132:85 Hold segment 4 start data point
PTS35 N132:86 Hold segment 5 start data point
PTS36 N132:87 Pre-decompress start data point
PTS37 N132:88 Plastication segment 1 start data point
PTS38 N132:89 Plastication segment 2 start data point
PTS39 N132:90 Plastication segment 3 start data point
PTS40 N132:91 Plastication segment 4 start data point
PTS41 N132:92 Plastication segment 5 start data point
PTS42 N132:93 Plastication segment 6 start data point
PTS43 N132:94 Plastication segment 7 start data point
PTS44 N132:95 Plastication segment 8 start data point
PTS45 N132:96 Plastication segment 9 start data point
PTS46 N132:97 Plastication segment 10 start data point
PTS47 N132:98 Plastication segment 11 start data point
PTS48 N132:99 Post-decompress start data point
PTS49 - 64 N132:100-115 RFU
Word Pro-Set Address Description
Bit-mapped Status Words
RLS01 B34:0 Block ID 00001000 (lower byte)
RLS01 B34:0 Jog status (upper byte)
RLS02 B34:1 Status of profile execution
RLS03 B34:2 Miscellaneous status
RLS04 B34:3 Status of watchdog timers
RLS05-08 N44:541-544 RFU
ERC Actuals from Injection Profile
RLS09 N44:545 Injection segment 1
RLS10 N44:546 Injection segment 2
RLS11 N44:547 Injection segment 3
RLS12 N44:548 Injection segment 4
RLS13 N44:549 Injection segment 5
RLS14 N44:550 Injection segment 6
RLS – Inject ERC Values
Status Block
