User Manual

1–45Abbreviated Command and Status Blocks
Publication 1771-6.5.88 – July 1997
PPS39 N44:743 Segment 8 execution time
PPS40 N44:744 End of Segment 8 position
PPS41 N44:745 Segment 9 RPM
PPS42 N44:746 Segment 9 pressure
PPS43 N44:747 Segment 9 execution time
PPS44 N44:748 End of Segment 9 position
PPS45 N44:749 Segment 10 RPM
PPS46 N44:750 Segment 10 pressure
PPS47 N44:751 Segment 10 execution time
PPS48 N44:752 End of Segment 10 position
PPS49 N44:753 Segment 11 RPM
PPS50 N44:754 Segment 11 pressure
PPS51 N44:755 Segment 11 execution time
PPS52 N44:756 RFU
Maximum Plastication Pressure
PPS53 N44:757 Ram (screw)
Maximum Post-decompression Pressure
PPS54 N44:758 Ram (screw)
PPS55-56 N44:759-760 RFU
Profile Execution Times
PPS57 N44:761 During plastication
PPS58 N44:762 During post-decompression
PPS59-60 N44:763-764 RFU
Actuals from Post-decompression Movement
PPS61 N44:765 Velocity
PPS62 N44:766 Pressure
Actual Shot Size
PPS63 N44:767 Total length
PPS64 N44:768 RFU
Word Pro-Set Address Description
Bit-mapped Status Words
PTS01 B131:0 Block ID 00001010 (lower byte)
PTS01 B131:1 Power up, jog execution status (hi byte)
PTS02 B131:2 Status of profile execution
PTS03 B131:3 Miscellaneous status
PTS04 B131:4 Status of watchdog timers
PTS05 B131:5 Trace selection
PTS06 B131:6 Trace data block number
PTS07-08 B131:7-8 RFU
PTS09 N132:60 Time to first trace data point
PTS10 N132:61 Trace data point count
PTS11-14 N132:62-65 RFU
PTS15 N132:66 Inject segment 1 start data point
PTS16 N132:67 Inject segment 2 start data point
PTS17 N132:68 Inject segment 3 start data point
PTS18 N132:69 Inject segment 4 start data point
PTS – Process Trace
Status Block
