User Manual

1–44 Abbreviated Command and Status Blocks
Publication 1771-6.5.88 – July 1997
Execution Times from Clamp Open Profiles
OPS57
N43:765 First profile
OPS58 N43:766 Second profile
OPS59 N43:767 Third profile
OPS60 N43:768 Open slow profile
OPS61-64 N43:769-772 RFU
Word Pro-Set Address Description
Bit-mapped Status Words
PPS01 B34:0 Block ID 00000101 (lower byte)
PPS01 B34:0 Jog status (upper byte)
PPS02 B34:1 Status of profile execution
PPS03 B34:2 Miscellaneous status
PPS04 B34:3 Status of watchdog timers
PPS05-06 B38:48-49 RFU
PPS07 B38:50 CV high limit alarms
PPS08 B38:51 CV low limit alarms
Actuals from Plastication Profile
PPS09 N44:713 Segment 1 RPM
PPS10 N44:714 Segment 1 pressure
PPS11 N44:715 Segment 1 execution time
PPS12 N44:716 End of Segment 1 position
PPS13 N44:717 Segment 2 RPM
PPS14 N44:718 Segment 2 pressure
PPS15 N44:719 Segment 2 execution time
PPS16 N44:720 End of Segment 2 position
PPS17 N44:721 Segment 3 RPM
PPS18 N44:722 Segment 3 pressure
PPS19 N44:723 Segment 3 execution time
PPS20 N44:724 End of Segment 3 position
PPS21 N44:725 Segment 4 RPM
PPS22 N44:726 Segment 4 pressure
PPS23 N44:727 Segment 4 execution time
PPS24 N44:728 End of Segment 4 position
PPS25 N44:729 Segment 5 RPM
PPS26 N44:730 Segment 5 pressure
PPS27 N44:731 Segment 5 execution time
PPS28 N44:732 End of Segment 5 position
PPS29 N44:733 Segment 6 RPM
PPS30 N44:734 Segment 6 pressure
PPS31 N44:735 Segment 6 execution time
PPS32 N44:736 End of Segment 6 position
PPS33 N44:737 Segment 7 RPM
PPS34 N44:738 Segment 7 pressure
PPS35 N44:739 Segment 7 execution time
PPS36 N44:740 End of Segment 7 position
PPS37 N44:741 Segment 8 RPM
PPS38 N44:742 Segment 8 pressure
PPS – Plastication Profile
Status Block
