1–42 Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
Actuals from Injection Profile
IPS27
N44:619 Segment 5 execution time
IPS28 N44:620 End of Segment 5 position
IPS29 N44:621 Segment 6 velocity
IPS30 N44:622 Segment 6 pressure
IPS31 N44:623 Segment 6 execution time
IPS32 N44:624 End of Segment 6 position
IPS33 N44:625 Segment 7 velocity
IPS34 N44:626 Segment 7 pressure
IPS35 N44:627 Segment 7 execution time
IPS36 N44:628 End of Segment 7 position
IPS37 N44:629 Segment 8 velocity
IPS38 N44:630 Segment 8 pressure
IPS39 N44:631 Segment 8 execution time
IPS40 N44:632 End of Segment 8 position
IPS41 N44:633 Segment 9 velocity
IPS42 N44:634 Segment 9 pressure
IPS43 N44:635 Segment 9 execution time
IPS44 N44:636 End of Segment 9 position
IPS45 N44:637 Segment 10 velocity
IPS46 N44:638 Segment 10 pressure
IPS47 N44:639 Segment 10 execution time
IPS48 N44:640 End of Segment 10 position
IPS49 N44:641 Segment 11 velocity
IPS50 N44:642 Segment 11 pressure
IPS51 N44:643 Segment 11 execution time
IPS52 N44:644 RFU
Maximum Pressures During Injection
IPS53 N44:645 Ram (screw)
IPS54 N44:646 Cavity
IPS55-60 N44:647-652 RFU
Transition Actuals
IPS61 N44:653 Time
IPS62 N44:654 Position
IPS63 N44:655 Ram (screw) pressure
IPS64 N44:656 Cavity pressure
Word Pro-Set Address Description
Bit-mapped Status Words
OPS01 B34:0 Block ID 00000110 (lower byte)
OPS01 B34:0 Jog status (upper byte)
OPS02 B34:1 Status of profile execution
OPS03 B34:2 Miscellaneous status
OPS04 B34:3 Status of watchdog timers
OPS05-06 B37:48-49 RFU
OPS07 B37:50 CV high limit alarms
OPS08 B37:51 CV low limit alarms
OPS – Clamp Open
Profiles Status Block
