1β41Abbreviated Command and Status Blocks
Publication
1771-6.5.88 β July 1997
Maximum Pressures During Hold
HPS53
N44:701 Ram (screw)
HPS54 N44:702 Cavity
Maximum Pressure During Pre-decompression
HPS55 N44:703 Ram (screw)
HPS56 N44:704 RFU
Profile Execution Times
HPS57 N44:705 During pack
HPS58 N44:706 During hold
HPS59 N44:707 During pre-decompression
HPS60 N44:708 RFU
Actuals from Pre-decompression Movement
HPS61 N44:709 Velocity
HPS62 N44:710 Pressure
End of Hold Ram (Screw) Position
HPS63 N44:711 Position at End of-hold
HPS64 N44:712 RFU
Word Pro-Set Address Description
Bit-mapped Status Words
IPS01 B34:0 Block ID 00000011 (lower byte)
IPS01 B34:0 Jog status (upper byte)
IPS02 B34:1 Status of profile execution
IPS03 B34:2 Miscellaneous status
IPS04 B34:3 Status of watchdog timers
IPS05 B38:40 Status of pressure limit alarms
IPS06 B38:41 Status of injection transitions
IPS07 B38:42 CV high limit alarms
IPS08 B38:43 CV low limit alarms
Actuals from Injection Profile
IPS09 N44:601 Segment 1 velocity
IPS10 N44:602 Segment 1 pressure
IPS11 N44:603 Segment 1 execution time
IPS12 N44:604 End of Segment 1 position
IPS13 N44:605 Segment 2 velocity
IPS14 N44:606 Segment 2 pressure
IPS15 N44:607 Segment 2 execution time
IPS16 N44:608 End of Segment 2 position
IPS17 N44:609 Segment 3 velocity
IPS18 N44:610 Segment 3 pressure
IPS19 N44:611 Segment 3 execution time
IPS20 N44:612 End of Segment 3 position
IPS21 N44:613 Segment 4 velocity
IPS22 N44:614 Segment 4 pressure
IPS23 N44:615 Segment 4 execution time
IPS24 N44:616 End of Segment 4 position
IPS25 N44:617 Segment 5 velocity
IPS26 N44:618 Segment 5 pressure
IPS β Injection Profile
Status Block
