1–40 Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
Word Pro-Set Address Description
Bit-mapped Status Words
HPS01 B34:0 Block ID 00000100 (lower byte)
HPS01 B34:0 Jog status (upper byte)
HPS02 B34:1 Status of profile execution
HPS03 B34:2 Miscellaneous status
HPS04 B34:3 Status of watchdog timers
HPS05-06 B38:44-45 RFU
HPS07 B38:46 CV high limit alarms
HPS08 B38:47 CV low limit alarms
Actuals from Pack Profile
HPS09 N44:657 Segment 1 cavity pressure
HPS10 N44:658 Segment 1 ram (screw) pressure
HPS11 N44:659 End of Segment 1 position
HPS12 N44:660 Segment 2 cavity pressure
HPS13 N44:661 Segment 2 ram (screw) pressure
HPS14 N44:662 End of Segment 2 position
HPS15 N44:663 Segment 3 cavity pressure
HPS16 N44:664 Segment 3 ram (screw) pressure
HPS17 N44:665 End of Segment 3 position
HPS18 N44:666 Segment 4 cavity pressure
HPS19 N44:667 Segment 4 ram (screw) pressure
HPS20 N44:668 End of Segment 4 position
HPS21 N44:669 Segment 5 cavity pressure
HPS22 N44:670 Segment 5 ram (screw) pressure
HPS23 N44:671 End of Segment 5 position
HPS24-25 N44:672 RFU
Actuals from Hold Profile
HPS26 N44:674 Segment 1 cavity pressure
HPS27 N44:675 Segment 1 ram (screw) pressure
HPS28 N44:676 End of Segment 1 position
HPS29 N44:677 Segment 2 cavity pressure
HPS30 N44:678 Segment 2 ram (screw) pressure
HPS31 N44:679 End of Segment 2 position
HPS32 N44:680 Segment 3 cavity pressure
HPS33 N44:681 Segment 3 ram (screw) pressure
HPS34 N44:682 End of Segment 3 position
HPS35 N44:6834 Segment 4 cavity pressure
HPS36 N44:684 Segment 4 ram (screw) pressure
HPS37 N44:685 End of Segment 4 position
HPS38 N44:686 Segment 5 cavity pressure
HPS39 N44:687 Segment 5 ram (screw) pressure
HPS40 N44:688 End of Segment 5 position
HPS41-50 N44:689-698 RFU
Maximum Pressures During Pack
HPS51 N44:699 Ram (screw)
HPS52 N44:700 Cavity
HPS – Pack/Hold Profile
Status Block
