User Manual

1–38 Abbreviated Command and Status Blocks
Publication 1771-6.5.88 – July 1997
Actuals from 2nd Clamp Close Profile
CPS18
N43:670 Segment 4 velocity
CPS19 N43:671 Segment 4 pressure
CPS20 N43:672 Segment 4 execution time
CPS21 N43:673 Segment 5 velocity
CPS22 N43:674 Segment 5 pressure
CPS23 N43:675 Segment 5 execution time
CPS24 N43:676 Segment 6 velocity
CPS25 N43:677 Segment 6 pressure
CPS26 N43:678 Segment 6 execution time
Actuals from 3rd Clamp Close Profile
CPS27 N43:679 Segment 7 velocity
CPS28 N43:680 Segment 7 pressure
CPS29 N43:681 Segment 7 execution time
CPS30 N43:682 Segment 8 velocity
CPS31 N43:683 Segment 8 pressure
CPS32 N43:684 Segment 8 execution time
CPS33 N43:685 Segment 9 velocity
CPS34 N43:686 Segment 9 pressure
CPS35 N43:687 Segment 9 execution time
Actuals from Clamp Low Pressure Close Profile
CPS36 N43:688 RFU
CPS37 N43:689 Segment 1 pressure
CPS38 N43:690 Segment 1 execution time
CPS39 N43:691 RFU
CPS40 N43:692 Segment 2 pressure
CPS41 N43:693 Segment 2 execution time
CPS42 N43:694 Starting velocity
CPS43 N43:695 Starting pressure
CPS44 N43:696 Starting position
CPS45 N43:697 Ending velocity
CPS46 N43:698 Ending pressure
Actuals from Clamp Low Pressure Close Profile
CPS47 N43:699 Ending position
CPS48-52 N43:700-704 RFU
Maximum Pressures During Clamp Close Profiles
CPS53 N43:705 During first profile
CPS54 N43:706 During second profile
CPS55 N43:707 During third profile
CPS56 N43:708 During LPC profile
Execution Times from Clamp Close Profiles
CPS57 N43:709 First profile
CPS58 N43:710 Second profile
CPS59 N43:711 Third profile
CPS60 N43:712 LPC profile
CPS61-64 N43:713-716 RFU
