1–37Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
CLS17 N43:613 Segment 9 (third clamp close)
CLS18 N43:614 Segment 1 (clamp LPC)
CLS19 N43:615 Segment 2 (clamp LPC)
CLS20 N43:616 Segment 1 (first clamp open)
CLS21 N43:617 Segment 2 (first clamp open)
CLS22 N43:618 Segment 3 (first clamp open)
CLS23 N43:619 Segment 4 (second clamp open)
CLS24 N43:620 Segment 5 (second clamp open)
CLS25 N43:621 Segment 6 (second clamp open)
CLS26 N43:622 Segment 7 (third clamp open)
CLS27 N43:623 Segment 8 (third clamp open)
CLS28 N43:624 Segment 9 (third clamp open)
CLS29 N43:625 Segment 1 (clamp open slow)
CLS30 N43:626 Segment 2 (clamp open slow)
ERC Actuals from Ejector Profile
CLS31 N43:627 Segment 1 (full advance)
CLS32 N43:628 Segment 2 (full advance)
CLS33 N43:629 Segment 3 (full advance)
CLS34 N43:630 RFU
CLS35 N43:631 Tip retract segment
CLS36 N43:632 RFU
CLS37 N43:633 Tip advance segment
CLS38 N43:634 RFU
CLS39 N43:635 Segment 1 (full retract)
CLS40 N43:636 Segment 2 (full retract)
CLS41 N43:637 Segment 3 (full retract)
CLS42-64 N43:638-660 RFU
Word Pro-Set Address Description
Bit-mapped Status Words
CPS01 B34:0 Block ID 00000010 (lower byte)
CPS01 B34:0 Jog status (upper byte)
CPS02 B34:1 Status of profile execution
CPS03 B34:2 Miscellaneous status
CPS04 B34:3 Status of watchdog timers
CPS05-06 B37:44-45 RFU
CPS07 B37:46 High limit alarms
CPS08 B37:47 Low limit alarms
Actuals from 1st Clamp Close Profile
CPS09 N43:661 Segment 1 velocity
CPS10 N43:662 Segment 1 pressure
CPS11 N43:663 Segment 1 execution time
CPS12 N43:664 Segment 2 velocity
CPS13 N43:665 Segment 2 pressure
CPS14 N43:666 Segment 2 execution time
CPS15 N43:667 Segment 3 velocity
CPS16 N43:668 Segment 3 pressure
CPS17 N43:669 Segment 3 execution time
CPS – Clamp Close
Profiles Status Block
