TCC52 N43:168 Proportional gain, velocity control
TCC53 N43:169 Feedforward gain, velocity control
TCC54-56 N43:170-172 RFU
Setpoint for Profile Pressure Alarm
TCC57 N43:173 High pressure alarm
TCC58-64 N43:174-180 RFU
Word Pro-Set Address Description
Bit-mapped Control Words
TOC01 B37:28 Block ID 00000000 00010011
TOC02 B37:29 Selected valve configurations
Bit-mapped Control Words
TOC03-04 B37:30-31 RFU
Expert Response Compensation Percentage
TOC05 N43:421 ERC % Minimum velocity
TOC06 N43:422 ERC % Minimum pressure
TOC07 N43:423 RFU
Watchdog Timer
TOC08 N43:424 Profile timer preset
Set-output Values for Unselected Valves (During Profile)
TOC09 N43:425 Output #1
TOC10 N43:426 Output #2
TOC11 N43:427 Output #3
TOC12 N43:428 Output #4
TOC13 N43:429 Output #5
TOC14 N43:430 Output #6
TOC15 N43:431 Output #7
TOC16 N43:432 Output #8
Acceleration Ramp Rates
TOC17 N43:433 Output #1
TOC18 N43:434 Output #2
TOC19 N43:435 Output #3
TOC20 N43:436 Output #4
TOC21 N43:437 Output #5
TOC22 N43:438 Output #6
TOC23 N43:439 Output #7
TOC24 N43:440 Output #8
Deceleration Ramp Rates
TOC25 N43:441 Output #1
TOC26 N43:442 Output #2
TOC27 N43:443 Output #3
TOC28 N43:444 Output #4
TOC29 N43:445 Output #5
TOC30 N43:446 Output #6
TOC31 N43:447 Output #7
TOC32 N43:448 Output #8
TOC – Third Clamp Open
Configuration Block
