User Manual

1–34 Abbreviated Command and Status Blocks
Publication 1771-6.5.88 – July 1997
Set-output Values for Unselected Valves (During Profile)
TCC09
N43:125 Output #1
TCC10 N43:126 Output #2
TCC11 N43:127 Output #3
TCC12 N43:128 Output #4
TCC13 N43:129 Output #5
TCC14 N43:130 Output #6
TCC15 N43:131 Output #7
TCC16 N43:132 Output #8
Acceleration Ramp Rates
TCC17 N43:133 Output #1
TCC18 N43:134 Output #2
TCC19 N43:135 Output #3
TCC20 N43:136 Output #4
TCC21 N43:137 Output #5
TCC22 N43:138 Output #6
TCC23 N43:139 Output #7
TCC24 N43:140 Output #8
Deceleration Ramp Rates
TCC25 N43:141 Output #1
TCC26 N43:142 Output #2
TCC27 N43:143 Output #3
TCC28 N43:144 Output #4
TCC29 N43:145 Output #5
TCC30 N43:146 Output #6
TCC31 N43:147 Output #7
TCC32 N43:148 Output #8
End of Profile Set-output Values
TCC33 N43:149 Output #1
TCC34 N43:150 Output #2
TCC35 N43:151 Output #3
TCC36 N43:152 Output #4
TCC37 N43:153 Output #5
TCC38 N43:154 Output #6
TCC39 N43:155 Output #7
TCC40 N43:156 Output #8
Pressure Control Limits
TCC41 N43:157 Minimum limit
TCC42 N43:158 Maximum limit
TCC43 N43:159 % output for minimum
TCC44 N43:160 % output for maximum
Velocity Control Limits
TCC45 N43:161 Minimum limit
TCC46 N43:162 Maximum limit
TCC47 N43:163 % output for minimum
TCC48 N43:164 % output for maximum
Profile Tuning Constants
TCC49 N43:165 Proportional gain, pressure control
TCC50 N43:166 Integral gain, pressure control
TCC51 N43:167 Derivative gain, pressure control
