1–33Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
SOC27 N43:383 Output #3
SOC28 N43:384 Output #4
SOC29 N43:385 Output #5
SOC30 N43:386 Output #6
SOC31 N43:387 Output #7
SOC32 N43:388 Output #8
End of Profile Set-output Values
SOC33 N43:389 Output #1
SOC34 N43:390 Output #2
SOC35 N43:391 Output #3
SOC36 N43:392 Output #4
SOC37 N43:393 Output #5
SOC38 N43:394 Output #6
SOC39 N43:395 Output #7
SOC40 N43:396 Output #8
Pressure Control Limits
SOC41 N43:397 Minimum limit
SOC42 N43:398 Maximum limit
SOC43 N43:399 % output for minimum
SOC44 N43:400 % output for maximum
Velocity Control Limits
SOC45 N43:401 Minimum limit
SOC46 N43:402 Maximum limit
SOC47 N43:403 % output for minimum
SOC48 N43:404 % output for maximum
Profile Tuning Constants
SOC49 N43:405 Proportional gain, pressure control
SOC50 N43:406 Integral gain, pressure control
SOC51 N43:407 Derivative gain, pressure control
SOC52 N43:408 Proportional gain, velocity control
SOC53 N43:409 Feedforward gain, velocity control
SOC54-56 N43:410-412 RFU
Setpoint for Profile Pressure Alarm
SOC57 N43:413 High pressure alarm
SOC58-64 N43:414-420 RFU
Word Pro-Set Address Description
Bit-mapped Control Words
TCC01 B37:8 Block ID 00000000 00000101
TCC02 B37:9 Selected valve configurations
TCC03-04 B37:10-11 RFU
Expert Response Compensation Percentage
TCC05 N43:121 ERC % minimum velocity
TCC06 N43:122 ERC % minimum pressure
TCC07 N43:123 RFU
Watchdog Timer
TCC08 N43:124 Profile watchdog timer
TCC – Third Clamp Close
Configuration Block
