1–31Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
Expert Response Compensation Percentage
SCC05
N43:61 ERC % minimum velocity
SCC06 N43:62 ERC % minimum pressure
SCC07 N43:63 RFU
Watchdog Timer
SCC08 N43:64 Profile watchdog timer
Set-output Values for Unselected Valves (During Profile)
SCC09 N43:65 Output #1
SCC10 N43:66 Output #2
SCC11 N43:67 Output #3
SCC12 N43:68 Output #4
SCC13 N43:69 Output #5
SCC14 N43:70 Output #6
SCC15 N43:71 Output #7
SCC16 N43:72 Output #8
Acceleration Ramp Rates
SCC17 N43:73 Output #1
SCC18 N43:74 Output #2
SCC19 N43:75 Output #3
SCC20 N43:76 Output #4
SCC21 N43:77 Output #5
SCC22 N43:78 Output #6
SCC23 N43:79 Output #7
SCC24 N43:80 Output #8
Deceleration Ramp Rates
SCC25 N43:81 Output #1
SCC26 N43:82 Output #2
SCC27 N43:83 Output #3
SCC28 N43:84 Output #4
SCC29 N43:85 Output #5
SCC30 N43:86 Output #6
SCC31 N43:87 Output #7
SCC32 N43:88 Output #8
End of Profile Set-output Values
SCC33 N43:89 Output #1
SCC34 N43:90 Output #2
SCC35 N43:91 Output #3
SCC36 N43:92 Output #4
SCC37 N43:93 Output #5
SCC38 N43:94 Output #6
SCC39 N43:95 Output #7
SCC40 N43:96 Output #8
Pressure Control Limits
SCC41 N43:97 Minimum limit
SCC42 N43:98 Maximum limit
SCC43 N43:99 % output for minimum
SCC44 N43:100 % output for maximum
