1–30 Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
Word Pro-Set Address Description
Bit-mapped Control Words
RLC01 B38:36 Block ID 00000000 00011010
RLC02-04 B38:37-39 RFU
ERC Values for Injection Profile
RLC05-08 N44:541-544 RFU
RLC09 N44:545 Injection segment 1
RLC10 N44:546 Injection segment 2
RLC11 N44:547 Injection segment 3
RLC12 N44:548 Injection segment 4
RLC13 N44:549 Injection segment 5
RLC14 N44:550 Injection segment 6
RLC15 N44:551 Injection segment 7
RLC16 N44:552 Injection segment 8
RLC17 N44:553 Injection segment 9
RLC18 N44:554 Injection segment 10
RLC19 N44:555 Injection segment 11
ERC Values for Pack Profile
RLC20 N44:556 Pack segment 1
RLC21 N44:557 Pack segment 2
RLC22 N44:558 Pack segment 3
RLC23 N44:559 Pack segment 4
RLC24 N44:560 Pack segment 5
ERC Values for Hold Profile
RLC25 N44:561 Hold segment 1
RLC26 N44:562 Hold segment 2
RLC27 N44:563 Hold segment 3
RLC28 N44:564 Hold segment 4
RLC29 N44:565 Hold segment 5
ERC Values for Plastication Profile
RLC30 N44:566 Plastication segment 1
RLC31 N44:567 Plastication segment 2
RLC32 N44:568 Plastication segment 3
RLC33 N44:569 Plastication segment 4
RLC34 N44:570 Plastication segment 5
RLC35 N44:571 Plastication segment 6
RLC36 N44:572 Plastication segment 7
RLC37 N44:573 Plastication segment 8
RLC38 N44:574 Plastication segment 9
RLC39 N44:575 Plastication segment 10
RLC40 N44:576 Plastication segment 11
RLC41-64 N44:577-600 RFU
Word Pro-Set Address Description
Bit-mapped Control Words
SCC01 B37:4 Block ID 00000000 00000100
SCC02 B37:5 Selected valve Configurations
SCC03-04 B37:6-7 RFU
RLC – Inject ERC Values
Block
SCC – Second Clamp
Close Configuration Block
