User Manual

1–29Abbreviated Command and Status Blocks
Publication 1771-6.5.88 – July 1997
Acceleration Ramp Rates
PSC17
N44:493 Output #1
PSC18 N44:494 Output #2
PSC19 N44:495 Output #3
PSC20 N44:496 Output #4
PSC21 N44:497 Output #5
PSC22 N44:498 Output #6
PSC23 N44:499 Output #7
PSC24 N44:500 Output #8
Deceleration Ramp Rates
PSC25 N44:501 Output #1
PSC26 N44:502 Output #2
PSC27 N44:503 Output #3
PSC28 N44:504 Output #4
PSC29 N44:505 Output #5
PSC30 N44:506 Output #6
PSC31 N44:507 Output #7
PSC32 N44:508 Output #8
End of Movement Set-output Values
PSC33 N44:509 Output #1
PSC34 N44:510 Output #2
PSC35 N44:511 Output #3
PSC36 N44:512 Output #4
PSC37 N44:513 Output #5
PSC38 N44:514 Output #6
PSC39 N44:515 Output #7
PSC40 N44:516 Output #8
PSC41-56 N44:517-532 RFU
Setpoint for Movement Pressure Alarm
PSC57 N44:533 High pressure alarm
PSC58-64 N44:534-40 RFU
Word Pro-Set Address Description
Bit-mapped Control Words
PTC01 B131:9 Block ID 00000000 00011100
PTC02 B131:10 Process trace and trigger control
PTC03-04 B131:11-12 Open
PTC05 N132:0 Trigger delay
PTC06 N132:1 Trigger position
PTC07 N132:2 Trace data collection sample rate
PTC08 N132:3 Trace 1 selection
PTC09 N132:4 Trace 2 selection
PTC10 N132:5 Trace 3 selection
PTC11 N132:6 Trace 4 selection
PTC12-64 N132:7-59 RFU
PTC – Process Trace
Configuration Block
