1β28 Abbreviated Command and Status Blocks
Publication
1771-6.5.88 β July 1997
PRC21 N44:317 Output #5
PRC22 N44:318 Output #6
PRC23 N44:319 Output #7
PRC24 N44:320 Output #8
Deceleration Ramp Rates
PRC25 N44:321 Output #1
PRC26 N44:322 Output #2
PRC27 N44:323 Output #3
PRC28 N44:324 Output #4
PRC29 N44:325 Output #5
PRC30 N44:326 Output #6
PRC31 N44:327 Output #7
PRC32 N44:328 Output #8
End of Movement Set-output Values
PRC33 N44:329 Output #1
PRC34 N44:330 Output #2
PRC35 N44:331 Output #3
PRC36 N44:332 Output #4
PRC37 N44:333 Output #5
PRC38 N44:334 Output #6
PRC39 N44:335 Output #7
PRC40 N44:336 Output #8
PRC41-56 N44:337-352 RFU
Setpoint for Movement Pressure Alarm
PRC57 N44:353 High pressure alarm
PRC58-64 N44:354-360 RFU
Word Pro-Set Address Description
Bit-mapped Control Words
PSC01 B38:32 Block ID 00000000 00010000
PSC02-04 B38:33-35 RFU
Movement Length
PSC05 N44:481 Length of post-decompress movement
PSC06-07 N44:482-483 RFU
Watchdog Timer
PSC08 N44:484 Movement timer preset
Set-output Values During Movement
PSC09 N44:485 Output #1
PSC10 N44:486 Output #2
PSC11 N44:487 Output #3
PSC12 N44:488 Output #4
PSC13 N44:489 Output #5
PSC14 N44:490 Output #6
PSC15 N44:491 Output #7
PSC16 N44:492 Output #8
PSC β
Post-decompression
Configuration Block
