PPC35 N44:451 End of Segment 7 position
PPC36 N44:452 Segment 7 time
PPC37 N44:453 Segment 8 RPM
PPC38 N44:454 Segment 8 pressure
PPC39 N44:455 End of Segment 8 position
PPC40 N44:456 Segment 8 time
PPC41 N44:457 Segment 9 RPM
PPC42 N44:458 Segment 9 pressure
PPC43 N44:459 End of Segment 9 position
PPC44 N44:460 Segment 9 time
PPC45 N44:461 Segment 10 RPM
PPC46 N44:462 Segment 10 pressure
PPC47 N44:463 End of Segment 10 position
PPC48 N44:464 Segment 10 time
PPC49 N44:465 Segment 11 RPM
PPC50 N44:466 Segment 11 pressure
Profile Offsets
PPC51 N44:467 RPM
PPC52 N44:468 Pressure
PPC53-60 N44:469-476 RFU
Critical Process Setpoints
PPC61 N44:477 Cushion
PPC62 N44:478 Shot size
PPC63-64 N44:479-480 RFU
Word Pro-Set Address Description
Bit-mapped Control Words
PRC01 B38:20 Block ID 00000000 00001101
PRC02-04 B38:21-23 RFU
Movement Length
PRC05 N44:301 Length of pre-decompress movement
PRC06-07 N44:302-303 RFU
Watchdog Timer
PRC08 N44:304 Movement timer preset
Set-output Values During Movement
PRC09 N44:305 Output #1
PRC10 N44:306 Output #2
PRC11 N44:307 Output #3
PRC12 N44:308 Output #4
PRC13 N44:309 Output #5
PRC14 N44:310 Output #6
PRC15 N44:311 Output #7
PRC16 N44:312 Output #8
Acceleration Ramp Rates
PRC17 N44:313 Output #1
PRC18 N44:314 Output #2
PRC19 N44:315 Output #3
PRC20 N44:316 Output #4
PRC – Pre-decompression
Configuration Block
