1–26 Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
PLC47 N44:403 % output for minimum
PLC48 N44:404 % output for maximum
Profile Tuning Constants
PLC49 N44:405 Proportional gain, pressure control
PLC50 N44:406 Integral gain, pressure control
PLC51 N44:407 Derivative gain, pressure control
PLC52 N44:408 Proportional gain, RPM control
PLC53 N44:409 Integral gain, RPM control
PLC54 N44:410 Derivative gain, RPM control
PLC55-56 N44:411-412 Open
Setpoint for Profile Pressure Alarm
PLC57 N44:413 High pressure alarm
PLC58-64 N44:414-420 RFU
Word Pro-Set Address Description
Bit-mapped Control Words
PPC01 B38:28 Block ID 00000000 00001111
PPC02 B38:29 RFU
PPC03 B38:30 Algorithm and logical bridging selections
PPC04 B38:31 Open/closed loop and ERC selections
Setpoints for Plastication Profile
PPC05-08 N44:421-424 RFU
PPC09 N44:425 Segment 1 RPM
PPC10 N44:426 Segment 1 pressure
PPC11 N44:427 End of Segment 1 position
PPC12 N44:428 Segment 1 time
PPC13 N44:429 Segment 2 RPM
PPC14 N44:430 Segment 2 pressure
PPC15 N44:431 End of Segment 2 position
PPC16 N44:432 Segment 2 time
PPC17 N44:433 Segment 3 RPM
PPC18 N44:434 Segment 3 pressure
PPC19 N44:435 End of Segment 3 position
PPC20 N44:436 Segment 3 time
PPC21 N44:437 Segment 4 RPM
PPC22 N44:438 Segment 4 pressure
PPC23 N44:439 End of Segment 4 position
PPC24 N44:440 Segment 4 time
PPC25 N44:441 Segment 5 RPM
PPC26 N44:442 Segment 5 pressure
PPC27 N44:443 End of Segment 5 position
PPC28 N44:444 Segment 5 time
PPC29 N044:445 Segment 6 RPM
PPC30 N44:446 Segment 6 pressure
PPC31 N44:447 End of Segment 6 position
PPC32 N44:448 Segment 6 time
PPC33 N44:449 Segment 7 RPM
PPC34 N44:450 Segment 7 pressure
PPC – Plastication
Profile Block
