User Manual

1–22 Abbreviated Command and Status Blocks
Publication 1771-6.5.88 – July 1997
Setpoints for Clamp Open Slow Profile (continued)
OPC38
N43:574 End of Segment 1 position
OPC39 N43:575 Segment 2 velocity
OPC40 N43:576 Segment 2 pressure
OPC41-60 N43:577-596 RFU
Critical Process Setpoints
OPC61 N43:597 Start position, clamp open slow
OPC62 N43:598 Full open position
OPC63 N43:599 Mold open dwell timer preset
OPC64 N43:600 RFU
Word Pro-Set Address Description
Bit-mapped Control Words
OSC01 B37:32 Block ID 00000000 00010100
OSC02 B37:33 Selected valve configurations
OSC03-04 B37:34-35 RFU
Expert Response Compensation Percentage
OSC05 N43:481 ERC % minimum velocity
OSC06 N43:482 ERC % minimum pressure
OSC07 N43:483 RFU
Watchdog Timer
OSC08 N43:484 Profile timer preset
Set-output Values for Unselected Valves (during Profile)
OSC09 N43:485 Output #1
OSC10 N43:486 Output #2
OSC11 N43:487 Output #3
OSC12 N43:488 Output #4
OSC13 N43:489 Output #5
OSC14 N43:490 Output #6
OSC15 N43:491 Output #7
OSC16 N43:492 Output #8
Acceleration Ramp Rates
OSC17 N43:493 Output #1
OSC18 N43:494 Output #2
OSC19 N43:495 Output #3
OSC20 N43:496 Output #4
OSC21 N43:497 Output #5
OSC22 N43:498 Output #6
OSC23 N43:499 Output #7
OSC24 N43:500 Output #8
Deceleration Ramp Rates
OSC25 N43:501 Output #1
OSC26 N43:502 Output #2
OSC27 N43:503 Output #3
OSC28 N43:504 Output #4
OSC29 N43:505 Output #5
OSC30 N43:506 Output #6
OSC31 N43:507 Output #7
OSC32 N43:508 Output #8
OSC – Clamp Open Slow
Configuration Block
