1–21Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
MCC60 N40:56 Analog signal @ max pressure
MCC61 N40:57 High pressure alarm setpoint
MCC62 N40:58 Time delay for pressure alarms
MCC63 N40:59 RFU
MCC64 N40:60 Number of input samples for loss-of-sensor alarms
Word Pro-Set Address Description
Bit-mapped Control Words
OPC01 B37:36 Block ID 00000000 00010101
OPC02 B37:37 RFU
OPC03 B37:38 Algorithm and logical bridging selections
OPC04 B37:39 Open/closed loop and ERC selections
Setpoints for 1st Clamp Open Profile
OPC05-08 N43:541 RFU
OPC09 N43:545 Segment 1 velocity
OPC10 N43:546 Segment 1 pressure
OPC11 N43:547 End of Segment 1 position
OPC12 N43:548 Segment 2 velocity
OPC13 N43:549 Segment 2 pressure
OPC14 N43:550 End of Segment 2 position
OPC15 N43:551 Segment 3 velocity
OPC16 N43:552 Segment 3 pressure
OPC17 N43:553 End of Segment 3 position
Setpoints for 2nd Clamp Open Profile
OPC18 N43:554 Segment 4 velocity
OPC19 N43:555 Segment 4 pressure
OPC20 N43:556 End of Segment 4 position
OPC21 N43:557 Segment 5 velocity
OPC22 N43:558 Segment 5 pressure
OPC23 N43:559 End of Segment 5 position
OPC24 N43:560 Segment 6 velocity
OPC25 N43:561 Segment 6 pressure
OPC26 N43:562 End of Segment 6 position
Setpoints for 3rd Clamp Open Profile
OPC27 N43:563 Segment 7 velocity
OPC28 N43:564 Segment 7 pressure
OPC29 N43:565 End of Segment 7 position
OPC30 N43:566 Segment 8 velocity
OPC31 N43:567 Segment 8 pressure
OPC32 N43:568 End of Segment 8 position
OPC33 N43:569 Segment 9 velocity
OPC34 N43:570 Segment 9 pressure
OPC35 N43:571 End of Segment 9 position
Setpoints for Clamp Open Slow Profile
OPC36 N43:572 Segment 1 velocity
OPC37 N43:573 Segment 1 pressure
OPC – Clamp Open
Profile Block
