1–19Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
LPC29 N43:205 Output #5
LPC30 N43:206 Output #6
LPC31 N43:207 Output #7
LPC32 N43:208 Output #8
End of Profile Set-output Values
LPC33 N43:209 Output #1
LPC34 N43:210 Output #2
LPC35 N43:211 Output #3
LPC36 N43:212 Output #4
LPC37 N43:213 Output #5
LPC38 N43:214 Output #6
LPC39 N43:215 Output #7
LPC40 N43:216 Output #8
Pressure Control Limits
LPC41 N43:217 Minimum limit
LPC42 N43:218 Maximum limit
LPC43 N43:219 % output for minimum
LPC44 N43:220 % output for maximum
LPC45-48 N43:221-224 RFU
Profile Tuning Constants
LPC49 N43:225 Proportional gain, pressure control
LPC50 N43:226 Integral gain, pressure control
LPC51 N43:227 Derivative gain, pressure control
LPC52-56 N43:228-232 RFU
Setpoint for Profile Pressure Alarm
LPC57 N43:233 High pressure alarm
LPC58-64 N43:234-240 RFU
Important: If using Pro-Set 600 and a QDC module configured for
Clamp/Eject mode, this data is found in alternate files B35 and N41.
Word Pro-Set Address Description
Bit-mapped Control Words
MCC01 B34:32 Block ID 00000000 00000001
MCC02 B34:33 Module density and operating modes
MCC03 B34:34 Input range selection
MCC04 B34:35 Output range selection
MCC05 N40:1 Output #1 stop position adjustment
MCC06 N40:2 Output #2 stop position adjustment
MCC07 N40:3 Output #3 stop position adjustment
MCC08 N40:4 Output #4 stop position adjustment
Ram (Screw) Position Sensor Configuration
MCC09 N40:5 Minimum position
MCC10 N40:6 Maximum position
MCC11 N40:7 Analog signal @ min position
MCC12 N40:8 Analog signal @ max position
MCC13 N40:9 Minimum SWTL (software travel limit)
MCC14 N40:10 Maximum SWTL
MCC15 N40:11 SWTL alarm deadband
MCC16 N40:12 Digital filter
MCC – Module
Configuration Command
Block
