1–18 Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
JGC53 N40:109 Output #5
JGC54 N40:110 Output #6
JGC55 N40:111 Output #7
JGC56 N40:112 Output #8
Ejector-retract-jog Set-output Values
JGC57 N40:113 Output #1
JGC58 N40:114 Output #2
JGC59 N40:115 Output #3
JGC60 N40:116 Output #4
JGC61 N40:117 Output #5
JGC62 N40:118 Output #6
JGC63 N40:119 Output #7
JGC64 N40:120 Output #8
Word Pro-Set Address Description
Bit-mapped Control Words
LPC01 B37:12 Block ID 00000000 00000110
LPC02 B37:13 Selected valve configurations
LPC03-04 B37:14-15 RFU
Expert Response Compensation Percentage
LPC05 N43:181 RFU
LPC06 N43:182 ERC % minimum pressure
Watchdog Timer
LPC07 N43:183 Tonnage timer preset
LPC08 N43:184 Profile timer preset
Set-output Values for Unselected Valves (During Profile)
LPC09 N43:185 Output #1
LPC10 N43:186 Output #2
LPC11 N43:187 Output #3
LPC12 N43:188 Output #4
LPC13 N43:189 Output #5
LPC14 N43:190 Output #6
LPC15 N43:191 Output #7
LPC16 N43:192 Output #8
Acceleration Ramp Rates
LPC17 N43:193 Output #1
LPC18 N43:194 Output #2
LPC19 N43:195 Output #3
LPC20 N43:196 Output #4
LPC21 N43:197 Output #5
LPC22 N43:198 Output #6
LPC23 N43:199 Output #7
LPC24 N43:200 Output #8
Deceleration Ramp Rates
LPC25 N43:201 Output #1
LPC26 N43:202 Output #2
LPC27 N43:203 Output #3
LPC28 N43:204 Output #4
LPC - Clamp Low Pressure
Close Configuration Block
