1β15Abbreviated Command and Status Blocks
Publication
1771-6.5.88 β July 1997
Profile Tuning Constants
INC49
N44:45 Proportional gain, pressure control
INC50 N44:46 Integral gain, pressure control
INC51 N44:47 Derivative gain, pressure control
INC52 N44:48 Proportional gain, velocity control
INC53 N44:49 Feedforward gain, velocity control
INC54-56 N44:50-52 RFU
Setpoints for Profile Pressure Alarms
INC57 N44:53 High ram (screw) pressure alarm
INC58 N44:54 High cavity pressure alarm
INC59-64 N44:55-60 RFU
Word Pro-Set Address Description
Bit-mapped Control Words
IPC01 B38:4 Block ID 00000000 00001001
Bit-mapped Control Words
IPC02 B38:5 RFU
IPC03 B38:6 Algorithm and offset polarity selections
IPC04 B38:7 Open/closed loop and ERC selections
Setpoints for Injection Profile
IPC05-08 N44:61-64 RFU
IPC09 N44:65 Segment 1 velocity
IPC10 N44:66 Segment 1 pressure
IPC11 N44:67 End of Segment 1 position
IPC12 N44:68 Segment 1 time
IPC13 N44:69 Segment 2 velocity
IPC14 N44:70 Segment 2 pressure
IPC15 N44:71 End of Segment 2 position
IPC16 N44:72 Segment 2 time
IPC17 N44:73 Segment 3 velocity
IPC18 N44:74 Segment 3 pressure
IPC19 N44:75 End of Segment 3 position
IPC20 N44:76 Segment 3 time
IPC21 N44:77 Segment 4 velocity
IPC22 N44:78 Segment 4 pressure
IPC23 N44:79 End of Segment 4 position
IPC24 N44:80 Segment 4 time
IPC25 N44:81 Segment 5 velocity
IPC26 N44:82 Segment 5 pressure
IPC27 N44:83 End of Segment 5 position
IPC28 N44:84 Segment 5 time
IPC29 N44:85 Segment 6 velocity
IPC30 N44:86 Segment 6 pressure
IPC31 N44:87 End of Segment 6 position
IPC32 N44:88 Segment 6 time
IPC33 N44:89 Segment 7 velocity
IPC34 N44:90 Segment 7 pressure
IPC35 N44:91 End of Segment 7 position
IPC β Injection
Profile Block
