1–14 Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
Word Pro-Set Address Description
Bit-mapped Control Words
INC01 B38:0 Block ID 00000000 00001000
INC02 B38:1 Selected valve configurations
INC03-04 B38:2-3 RFU
Expert Response Compensation Percentage
INC05 N44:1 ERC % minimum velocity
INC06 N44:2 ERC % minimum pressure
INC07 N44:3 RFU
INC08 N44:4 RFU
Set-output Values for Unselected Valves (During Profile)
INC09 N44:5 Output #1
INC10 N44:6 Output #2
INC11 N44:7 Output #3
INC12 N44:8 Output #4
INC13 N44:9 Output #5
INC14 N44:10 Output #6
INC15 N44:11 Output #7
INC16 N44:12 Output #8
Acceleration Ramp Rates
INC17 N44:13 Output #1
INC18 N44:14 Output #2
INC19 N44:15 Output #3
INC20 N44:16 Output #4
INC21 N44:17 Output #5
INC22 N44:18 Output #6
INC23 N44:19 Output #7
INC24 N44:20 Output #8
Deceleration Ramp Rates
INC25 N44:21 Output #1
INC26 N44:22 Output #2
INC27 N44:23 Output #3
INC28 N44:24 Output #4
INC29 N44:25 Output #5
INC30 N44:26 Output #6
INC31 N44:27 Output #7
INC32 N44:28 Output #8
INC33-40 N44:29-36 RFU
Pressure Control Limits
INC41 N44:37 Minimum limit
INC42 N44:38 Maximum limit
INC43 N44:39 % output for minimum
INC44 N44:40 % output for maximum
Velocity Control Limits
INC45 N44:41 Minimum limit
INC46 N44:42 Maximum limit
INC47 N44:43 % output for minimum
INC48 N44:44 % output for maximum
INC – Injection
Configuration Block
