1–13Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
Word Pro-Set Address Description
Bit-mapped Control Words
HPC01 B38:16 Block ID 00000000 00001100
HPC02 B38:17 RFU
HPC03 B38:18 Algorithm and logical bridging selections
HPC04 B38:19 Open/closed loop and ERC selections
Setpoints for Pack Profile
HPC05-08 N44:241-244 RFU
HPC09 N44:245 Segment 1 cavity pressure
HPC10 N44:246 Segment 1 ram (screw) pressure
HPC11 N44:247 Segment 1 time
HPC12 N44:248 Segment 2 cavity pressure
HPC13 N44:249 Segment 2 ram (screw) pressure
HPC14 N44:250 Segment 2 time
HPC15 N44:251 Segment 3 cavity pressure
HPC16 N44:252 Segment 3 ram (screw) pressure
HPC17 N44:253 Segment 3 time
HPC18 N44:254 Segment 4 cavity pressure
HPC19 N44:255 Segment 4 ram (screw) pressure
HPC20 N44:256 Segment 4 time
HPC21 N44:257 Segment 5 cavity pressure
HPC22 N44:258 Segment 5 ram (screw) pressure
HPC23 N44:259 Segment 5 time
Pack Profile Offsets
HPC24 N44:260 Cavity pressure
HPC25 N44:261 Ram (screw) pressure
Setpoints for Hold Profile
HPC26 N44:262 Segment 1 cavity pressure
HPC27 N44:263 Segment 1 ram (screw) pressure
HPC28 N44:264 Segment 1 time
HPC29 N44:265 Segment 2 cavity pressure
HPC30 N44:266 Segment 2 ram (screw) pressure
HPC31 N44:267 Segment 2 time
HPC32 N44:268 Segment 3 cavity pressure
HPC33 N44:269 Segment 3 ram (screw) pressure
HPC34 N44:270 Segment 3 time
HPC35 N44:271 Segment 4 cavity pressure
HPC36 N44:272 Segment 4 ram (screw) pressure
HPC37 N44:273 Segment 4 time
HPC38 N44:274 Segment 5 cavity pressure
HPC39 N44:275 Segment 5 ram (screw) pressure
HPC40 N44:276 Segment 5 time
Hold Profile Offsets
HPC41 N44:277 Cavity pressure
HPC42 N44:278 Ram (screw) pressure
HPC43-60 N44:279-296 RFU
Critical Process Setpoints
HPC61 N44:297 Cure timer preset
HPC62-64 N44:298-300 RFU
HPC – Pack/Hold
Profile Block
