1–12 Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
Acceleration Ramp Rates
HDC17
N44:193 Output #1
HDC18 N44:194 Output #2
HDC19 N44:195 Output #3
HDC20 N44:196 Output #4
HDC21 N44:197 Output #5
HDC22 N44:198 Output #6
HDC23 N44:199 Output #7
HDC24 N44:200 Output #8
Deceleration Ramp Rates
HDC25 N44:201 Output #1
HDC26 N44:202 Output #2
HDC27 N44:203 Output #3
HDC28 N44:204 Output #4
HDC29 N44:205 Output #5
HDC30 N44:206 Output #6
HDC31 N44:207 Output #7
HDC32 N44:208 Output #8
End of Profile Set-output Values
HDC33 N44:209 Output #1
HDC34 N44:210 Output #2
HDC35 N44:211 Output #3
HDC36 N44:212 Output #4
HDC37 N44:213 Output #5
HDC38 N44:214 Output #6
HDC39 N44:215 Output #7
HDC40 N44:216 Output #8
Ram (Screw) Pressure Control Limits
HDC41 N44:217 Minimum limit
HDC42 N44:218 Maximum limit
HDC43 N44:219 % output for minimum
HDC44 N44:220 % output for maximum
Cavity Pressure Control Limits
HDC45 N44:221 Minimum limit
HDC46 N44:222 Maximum limit
HDC47 N44:223 % output for minimum
HDC48 N44:224 % output for maximum
Profile Tuning Constants
HDC49 N44:225 Proportional gain, ram (screw) pressure control
HDC50 N44:226 Integral gain, ram (screw) pressure control
HDC51 N44:227 Derivative gain, ram (screw) pressure control
HDC52 N44:228 Proportional gain, cavity pressure control
HDC53 N44:229 Integral gain, cavity pressure control
HDC54 N44:230 Derivative gain, cavity pressure control
HDC55-56 N44:231-232 RFU
Setpoints for Profile Pressure Alarms
HDC57 N44:233 High ram (screw) pressure alarm
HDC58 N44:234 High cavity pressure alarm
HDC59-64 N44:235-240 RFU
