1–11Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
End of Profile Set-output Values
FOC33
N43:329 Output #1
FOC34 N43:330 Output #2
FOC35 N43:331 Output #3
FOC36 N43:332 Output #4
FOC37 N43:333 Output #5
FOC38 N43:334 Output #6
FOC39 N43:335 Output #7
FOC40 N43:336 Output #8
Pressure Control Limits
FOC41 N43:337 Minimum limit
FOC42 N43:338 Maximum limit
FOC43 N43:339 % output for minimum
FOC44 N43:340 % output for maximum
Velocity Control Limits
FOC45 N43:341 Minimum limit
FOC46 N43:342 Maximum limit
FOC47 N43:343 Minimum output for selected velocity valve
FOC48 N43:344 Maximum output for selected velocity valve
Profile Tuning Constants
FOC49 N43:345 Proportional gain, pressure control
FOC50 N43:346 Integral gain, pressure control
FOC51 N43:347 Derivative gain, pressure control
FOC52 N43:348 Proportional gain, velocity control
FOC53 N43:349 Feedforward gain, velocity control
FOC54-56 N43:350-352 RFU
Setpoints for Profile Pressure Alarm
FOC57 N43:353 High pressure alarm
FOC58-64 N43:354-360 RFU
Word Pro-Set Address Description
Bit-mapped Control Words
HDC01 B38:12 Block ID 00000000 00001011
HDC02 B38:13 Selected valve configurations
HDC03-04 B38:14-15 RFU
Expert Response Compensation Percentage
HDC05 N44:181 ERC % minimum cavity pressure
HDC06 N44:182 ERC % minimum ram pressure
HDC07-08 N44:183-184 RFU
Set-output Values for Unselected Valves (During Profile)
HDC09 N44:185 Output #1
HDC10 N44:186 Output #2
HDC11 N44:187 Output #3
HDC12 N44:188 Output #4
HDC13 N44:189 Output #5
HDC14 N44:190 Output #6
HDC15 N44:191 Output #7
HDC16 N44:192 Output #8
HDC – Hold
Configuration Block
