4–55Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 24
0461 EPC61 is out of range.
if: then:
MCC27 and MCC28 EPC61 must be within EPC62 < EPC61 ≤ MCC28 – MCC27
are both non-zero
MCC27 is non-zero and EPC61 must be within EPC62 < EPC61 ≤ MCC24 – MCC27
MCC28 is zero
MCC27 is zero and EPC61 must be within EPC62 < EPC61 ≤ MCC28 – MCC23
MCC28 is non-zero
MCC27 and MCC28 EPC61 must be within EPC62 < EPC61 ≤ MCC24 – MCC23
are both zero
0462
EPC62 is out of range. Valid range is 00000 ≤ EPC62 < EPC61
0463
EPC63 is out of range. Valid range is EPC60 ≤ EPC63 < EPC59
0503 Your selection to start the Ejector Profile based upon clamp position during the Clamp Open
Profile is invalid because QDC module does not have a valid OPC (SYS16-B04 = 0).
0504 You have selected closed-loop Press/Pos execution for the Ejector Profile by EPC04-B01 = 0;
however, your bit patterns in MCC02 and MCC03 indicate that the QDC module does not
have access to a connected ejector pressure transducer.
0600 Your entire Ejector Profile Command Block has been rejected because the QDC module does
not have both a valid Ejector Advance Configuration Command Block and a valid Ejector
Retract Configuration Command Block on-board.
0812 EPC12 must be 00000 when EPC11 = 00000.
0813 EPC13 must be 00000 when EPC11 = 00000.
0814 EPC14 must be 00000 when EPC11 = 00000.
0815 EPC15 must be 00000 when EPC14 = 00000.
0816 EPC16 must be 00000 when EPC14 = 00000.
0836 EPC36 must be 00000 when EPC35 = 00000.
0837 EPC37 must be 00000 when EPC35 = 00000.
0838 EPC38 must be 00000 when EPC35 = 00000.
0839 EPC39 must be 00000 when EPC38 = 00000.
0840 EPC40 must be 00000 when EPC38 = 00000.
1014 EPC14 is not in increasing positional order.
If non-zero, EPC14 must be greater than EPC11.
1038 EPC38 is not in decreasing positional order.
If non-zero, EPC38 must be less than EPC35.
ID = 25 DYC – Dynamic Command Block
Error Code
Description ID = 25
0209
DYC09 is out of range. Valid range is 00000 ≤ DYC09 ≤ 09999
0210
DYC10 is out of range. Valid range is 00000 ≤ DYC10 ≤ 09999
0211
DYC11 is out of range. Valid range is 00000 ≤ DYC11 ≤ 09999
0212
DYC12 is out of range. Valid range is 00000 ≤ DYC12 ≤ 09999
0213
DYC13 is out of range. Valid range is 00000 ≤ DYC13 ≤ 09999
0214
DYC14 is out of range. Valid range is 00000 ≤ DYC14 ≤ 09999
0215
DYC15 is out of range. Valid range is 00000 ≤ DYC15 ≤ 09999
0216
DYC16 is out of range. Valid range is 00000 ≤ DYC16 ≤ 09999
0217
DYC17 is out of range. Valid range is 00000 ≤ DYC17 ≤ 09999
0218
DYC18 is out of range. Valid range is 00000 ≤ DYC18 ≤ 09999
0219
DYC19 is out of range. Valid range is 00000 ≤ DYC19 ≤ 09999
0220
DYC20 is out of range. Valid range is 00000 ≤ DYC20 ≤ 09999
