User Manual

4–54 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 24
0429 EPC29 is out of range.
if: then:
MCC41 and MCC42 EPC29 must be within 00000 ≤ EPC29 ≤ MCC42 – MCC41
are both non-zero
MCC41 is non-zero and EPC29 must be within 00000 ≤ EPC29 ≤ MCC38 – MCC41
MCC42 is zero
MCC41 is zero and EPC29 must be within 00000 ≤ EPC29 ≤ MCC42 – MCC37
MCC42 is non-zero
MCC41 and MCC42 EPC29 must be within 00000 ≤ EPC29 ≤ MCC38 – MCC37
are both zero
0433 EPC33 is out of range. When EPC03-B14 = 1, a non-zero entry for EPC33 must be within
ERC45
≤ EPC33 ≤ ERC46
0434
EPC34 is out of range. If non-zero, EPC34 must be within ERC41 ≤ EPC34 ≤ ERC42
0435 EPC35 is out of range.
if: then:
MCC41 and MCC42 EPC35 must be within 00000 ≤ EPC35 < MCC42 – MCC41
are both non-zero
MCC41 is non-zero and EPC35 must be within 00000 ≤ EPC35 ≤ MCC38 – MCC41
MCC42 is zero
MCC41 is zero and EPC35 must be within 00000 ≤ EPC35 < MCC42 – MCC37
MCC42 is non-zero
MCC41 and MCC42 EPC35 must be within 00000 ≤ EPC35 ≤ MCC38 – MCC37
are both zero
0436 EPC36 is out of range. When EPC03-B14 = 1, a non-zero entry for EPC36 must be within
ERC45
≤ EPC36 ≤ ERC46
0437
EPC37 is out of range. If non-zero, EPC37 must be within ERC41 ≤ EPC37 ≤ ERC42
0438 EPC38 is out of range.
if: then:
MCC41 and MCC42 EPC38 must be within 00000 ≤ EPC38 ≤ MCC42 – MCC41
are both non-zero
MCC41 is non-zero and EPC38 must be within 00000 ≤ EPC38 ≤ MCC38 – MCC41
MCC42 is zero
MCC41 is zero and EPC38 must be within 00000 ≤ EPC38 ≤ MCC42 – MCC37
MCC42 is non-zero
MCC41 and MCC42 EPC38 must be within 00000 ≤ EPC38 ≤ MCC38 – MCC37
are both zero
0439 EPC39 is out of range. When EPC03-B14 = 1, a non-zero entry for EPC39 must be within
ERC45
≤ EPC39 ≤ ERC46
0440
EPC40 is out of range. If non-zero, EPC40 must be within ERC41 ≤ EPC40 ≤ ERC42
0459 EPC59 is out of range.
if: then:
MCC41 and MCC42 EPC59 must be within EPC60 < EPC59 ≤ MCC42 – MCC41
are both non-zero
MCC41 is non-zero and EPC59 must be within EPC60 < EPC59 ≤ MCC38 – MCC41
MCC42 is zero
MCC41 is zero and EPC59 must be within EPC60 < EPC59 ≤ MCC42 – MCC37
MCC42 is non-zero
MCC41 and MCC42 EPC59 must be within EPC60 < EPC59 ≤ MCC38 – MCC37
are both zero
0460
EPC60 is out of range. Valid range is 00000 ≤ EPC60 < EPC59
