4–53Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 24
0236 EPC36 is out of range.
When EPC03-B14 = 0, EPC36 must be within 00000
≤ EPC36 ≤ 09999
0239 EPC39 is out of range.
When EPC03-B14 = 0, EPC39 must be within 00000
≤ EPC39 ≤ 09999
0257
EPC57 is out of range. Valid range is 00000 ≤ EPC57 ≤ 09999
0264
EPC64 is out of range. Valid range is 00000 ≤ EPC64 ≤ 09999
0409 EPC09 is out of range. When EPC03-B14 = 1, a non-zero entry for EPC09 must be within
EAC45
≤ EPC09 ≤ EAC46
0410
EPC10 is out of range. If non-zero, EPC10 must be within EAC41 ≤ EPC10 ≤ EAC42
0411 EPC11 is out of range.
if: then:
MCC41 and MCC42 EPC11 must be within 00000 ≤ EPC11 ≤ MCC42 – MCC41
are both non-zero
MCC41 is non-zero and EPC11 must be within 00000 ≤ EPC11 ≤ MCC38 – MCC41
MCC42 is zero
MCC41 is zero and EPC11 must be within 00000 ≤ EPC11 ≤ MCC42 – MCC37
MCC42 is non-zero
MCC41 and MCC42 EPC11 must be within 00000 ≤ EPC11 ≤ MCC38 – MCC37
are both zero
0412 EPC12 is out of range. When EPC03-B14 = 1, a non-zero entry for EPC12 must be within
EAC45
≤ EPC12 ≤ EAC46
0413
EPC13 is out of range. If non-zero, EPC13 must be within EAC41 ≤ EPC13 ≤ EAC42
0414 EPC14 is out of range.
if: then:
MCC41 and MCC42 EPC14 must be within 00000 ≤ EPC14 ≤ MCC42 – MCC41
are both non-zero
MCC41 is non-zero and EPC14 must be within 00000 ≤ EPC14 ≤ MCC38 – MCC41
MCC42 is zero
MCC41 is zero and EPC14 must be within 00000 ≤ EPC14 ≤ MCC42 – MCC37
MCC42 is non-zero
MCC41 and MCC42 EPC14 must be within 00000 ≤ EPC14 ≤ MCC38 – MCC37
are both zero
0415 EPC15 is out of range. When EPC03-B14 = 1, a non-zero entry for EPC15 must be within
EAC45
≤ EPC15 ≤ EAC46
0416
EPC16 is out of range. If non-zero, EPC16 must be within EAC41 ≤ EPC16 ≤ EAC42
0421 EPC21 is out of range. When EPC03-B14 = 1, a non-zero entry for EPC21 must be within
ERC45
≤ EPC21 ≤ ERC46
0422
EPC22 is out of range. If non-zero, EPC22 must be within ERC41 ≤ EPC22 ≤ ERC42
0423 EPC23 is out of range.
if: then:
MCC41 and MCC42 EPC23 must be within 00000 ≤ EPC23 ≤ MCC42 – MCC41
are both non-zero
MCC41 is non-zero and EPC23 must be within 00000 ≤ EPC23 ≤ MCC38 – MCC41
MCC42 is zero
MCC41 is zero and EPC23 must be within 00000 ≤ EPC23 ≤ MCC42 – MCC37
MCC42 is non-zero
MCC41 and MCC42 EPC23 must be within 00000 ≤ EPC23 ≤ MCC38 – MCC37
are both zero
0427 EPC27 is out of range. When EPC03-B14 = 1, a non-zero entry for EPC27 must be within
EAC45
≤ EPC27 ≤ EAC46
0428
EPC28 is out of range. If non-zero, EPC28 must be within EAC41 ≤ EPC28 ≤ EAC42
