User Manual

4–52 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 23
0228
ERC28 is out of range. Valid range is 00000 ≤ ERC28 ≤ 09999
0229
ERC29 is out of range. Valid range is 00000 ≤ ERC29 ≤ 09999
0230
ERC30 is out of range. Valid range is 00000 ≤ ERC30 ≤ 09999
0231
ERC31 is out of range. Valid range is 00000 ≤ ERC31 ≤ 09999
0232
ERC32 is out of range. Valid range is 00000 ≤ ERC32 ≤ 09999
0233
ERC33 is out of range. Valid range is 00000 ≤ ERC33 ≤ 09999
0234
ERC34 is out of range. Valid range is 00000 ≤ ERC34 ≤ 09999
0235
ERC35 is out of range. Valid range is 00000 ≤ ERC35 ≤ 09999
0236
ERC36 is out of range. Valid range is 00000 ≤ ERC36 ≤ 09999
0237
ERC37 is out of range. Valid range is 00000 ≤ ERC37 ≤ 09999
0238
ERC38 is out of range. Valid range is 00000 ≤ ERC38 ≤ 09999
0239
ERC39 is out of range. Valid range is 00000 ≤ ERC39 ≤ 09999
0240
ERC40 is out of range. Valid range is 00000 ≤ ERC40 ≤ 09999
0243
ERC43 is out of range. Valid range is 00000 ≤ ERC43 ≤ 09999
0244
ERC44 is out of range. Valid range is 00000 ≤ ERC44 ≤ 09999
0247
ERC47 is out of range. Valid range is 00000 ≤ ERC47 ≤ 09999
0248
ERC48 is out of range. Valid range is 00000 ≤ ERC48 ≤ 09999
0249
ERC49 is out of range. Valid range is 00000 ≤ ERC49 ≤ 09999
0250
ERC50 is out of range. Valid range is 00000 ≤ ERC50 ≤ 09999
0251
ERC51 is out of range. Valid range is 00000 ≤ ERC51 ≤ 09999
0252
ERC52 is out of range. Valid range is 00000 ≤ ERC52 ≤ 09999
0253
ERC53 is out of range. Valid range is 00000 ≤ ERC53 ≤ 09999
0343 ERC43 is equal to ERC44. They must not be equal.
0347 ERC47 is equal to ERC48. They must not be equal.
0441
ERC41 is out of range. Valid range is 00000 ≤ ERC41 < ERC42
0442
ERC42 is out of range. Valid range is ERC41 < ERC42 ≤ 09999
0445
ERC45 is out of range. Valid range is 00000 ≤ ERC45 < ERC46
0446
ERC46 is out of range. Valid range is ERC45 < ERC46 ≤ 09999
0502 Your bit pattern in ERC02-B02, ERC02-B01, and ERC02-B00 indicates a selected ejector
velocity control valve that is unconnected according to your entries in MCC02 and MCC04.
0506 Your bit pattern in ERC02-B06, ERC02-B05, and ERC02-B04 indicates a selected ejector
pressure control valve that is unconnected according to your entries in MCC02 and MCC04.
ID = 24 EPC – Ejector Profile Block
Error Code
Description ID = 24
0209 EPC09 is out of range.
When EPC03-B14 = 0, EPC09 must be within 00000
≤ EPC09 ≤ 09999
0212 EPC12 is out of range.
When EPC03-B14 = 0, EPC12 must be within 00000
≤ EPC12 ≤ 09999
0215 EPC15 is out of range.
When EPC03-B14 = 0, EPC15 must be within 00000
≤ EPC15 ≤ 09999
0221 EPC21 is out of range.
When EPC03-B14 = 0, EPC21 must be within 00000
≤ EPC21 ≤ 09999
0227 EPC27 is out of range.
When EPC03-B14 = 0, EPC27 must be within 00000
≤ EPC27 ≤ 09999
0233 EPC33 is out of range.
When EPC03-B14 = 0, EPC33 must be within 00000
≤ EPC33 ≤ 09999
