4–51Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 22
0240
EAC40 is out of range. Valid range is 00000 ≤ EAC40 ≤ 09999
0243
EAC43 is out of range. Valid range is 00000 ≤ EAC43 ≤ 09999
0244
EAC44 is out of range. Valid range is 00000 ≤ EAC44 ≤ 09999
0247
EAC47 is out of range. Valid range is 00000 ≤ EAC47 ≤ 09999
0248
EAC48 is out of range. Valid range is 00000 ≤ EAC48 ≤ 09999
0249
EAC49 is out of range. Valid range is 00000 ≤ EAC49 ≤ 09999
0250
EAC50 is out of range. Valid range is 00000 ≤ EAC50 ≤ 09999
0251
EAC51 is out of range. Valid range is 00000 ≤ EAC51 ≤ 09999
0252
EAC52 is out of range. Valid range is 00000 ≤ EAC52 ≤ 09999
0253
EAC53 is out of range. Valid range is 00000 ≤ EAC53 ≤ 09999
0343 EAC43 is equal to EAC44. They must not be equal.
0347 EAC47 is equal to EAC48. They must not be equal.
0441
EAC41 is out of range. Valid range is 00000 ≤ EAC41 < EAC42
0442
EAC42 is out of range. Valid range is EAC41 < EAC42 ≤ 09999
0445
EAC45 is out of range. Valid range is 00000 ≤ EAC45 < EAC46
0446
EAC46 is out of range. Valid range is EAC45 < EAC46 ≤ 09999
0457 EAC57 is out of range.
If non-zero, EAC57 must be within MCC45 < EAC57
≤ MCC46
0502 Your bit pattern in EAC02-B02, EAC02-B01, and EAC02-B00 indicates a selected ejector
velocity control valve that is unconnected according to your entries in MCC02 and MCC04.
0506 Your bit pattern in EAC02-B06, EAC02-B05, and EAC02-B04 indicates a selected ejector
pressure control valve that is unconnected according to your entries in MCC02 and MCC04.
ID = 23 ERC – Ejector Retract Configuration Block
Error Code
Description ID = 23
0205
ERC05 is out of range. Valid range is 00000 ≤ ERC05 ≤ 09999
0206
ERC06 is out of range. Valid range is 00000 ≤ ERC06 ≤ 09999
0209
ERC09 is out of range. Valid range is 00000 ≤ ERC09 ≤ 09999
0210
ERC10 is out of range. Valid range is 00000 ≤ ERC10 ≤ 09999
0211
ERC11 is out of range. Valid range is 00000 ≤ ERC11 ≤ 09999
0212
ERC12 is out of range. Valid range is 00000 ≤ ERC12 ≤ 09999
0213
ERC13 is out of range. Valid range is 00000 ≤ ERC13 ≤ 09999
0214
ERC14 is out of range. Valid range is 00000 ≤ ERC14 ≤ 09999
0215
ERC15 is out of range. Valid range is 00000 ≤ ERC15 ≤ 09999
0216
ERC16 is out of range. Valid range is 00000 ≤ ERC16 ≤ 09999
0217
ERC17 is out of range. Valid range is 00000 ≤ ERC17 ≤ 09999
0218
ERC18 is out of range. Valid range is 00000 ≤ ERC18 ≤ 09999
0219
ERC19 is out of range. Valid range is 00000 ≤ ERC19 ≤ 09999
0220
ERC20 is out of range. Valid range is 00000 ≤ ERC20 ≤ 09999
0221
ERC21 is out of range. Valid range is 00000 ≤ ERC21 ≤ 09999
0222
ERC22 is out of range. Valid range is 00000 ≤ ERC22 ≤ 09999
0223
ERC23 is out of range. Valid range is 00000 ≤ ERC23 ≤ 09999
0224
ERC24 is out of range. Valid range is 00000 ≤ ERC24 ≤ 09999
0225
ERC25 is out of range. Valid range is 00000 ≤ ERC25 ≤ 09999
0226
ERC26 is out of range. Valid range is 00000 ≤ ERC26 ≤ 09999
0227
ERC27 is out of range. Valid range is 00000 ≤ ERC27 ≤ 09999
