User Manual

4–48 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 21
MCC27 is zero and OPC62 must be within OPC61 < OPC62 ≤ MCC28 – MCC23.
MCC28 is non-zero
MCC27 and MCC28 OPC62 must be within OPC61 < OPC62 ≤ MCC24 – MCC23
are both zero
0503 Your selection to bridge the First Clamp Open Profile directly into Second Clamp Open Profile,
and set-output upon conclusion of Second Clamp Open Profile (OPC03-B08 = 0 and
OPC03-B09 = 1) is invalid because QDC module does not have a valid SOC (SYS16-B01 = 0).
0504 You have selected closed-loop Press/Pos execution for the First Clamp Open Profile by
OPC04-B01 = 0; however, your bit patterns in MCC02 and MCC03 indicate that the QDC mod-
ule does not have access to a connected clamp pressure transducer.
0507 Your selection to bridge the first two Clamp Open Profiles directly into the Third Clamp Open
Profile, and set-output upon conclusion of the Third Clamp Open Profile (OPC03-B08 = 0,
OPC03-B09 = 0, and OPC03-B10 = 1) is invalid because the QDC module does not have a valid
TOC on-board (SYS16-B02 = 0).
0508 You have selected closed-loop Press/Pos execution for the Second Clamp Open Profile by
OPC04-B03 = 0; however, your bit patterns in MCC02 and MCC03 indicate that the QDC mod-
ule does not have access to a connected clamp pressure transducer.
0511 Your selection to bridge the Second Clamp Open Profile directly into the Third Clamp Open
Profile, and set-output upon conclusion of the Third Clamp Open Profile (OPC03-B09 = 0, and
OPC03-B10 = 1) is invalid because the QDC module does not have a valid TOC on-board
(SYS16-B02 = 0).
0512 You have selected closed-loop Press/Pos execution for the Third Clamp Open Profile by
OPC04-B05 = 0; however, your bit patterns in MCC02 and MCC03 indicate that the QDC mod-
ule does not have access to a connected clamp pressure transducer.
0516 You have selected closed-loop Press/Pos execution for the Clamp Open Slow Profile by
OPC04-B07 = 0; however, your bit patterns in MCC02 and MCC03 indicate that the QDC mod-
ule does not have access to a connected clamp pressure transducer.
0600 Your entire Clamp Open Profile Command Block has been rejected because the QDC module
does not have a valid Clamp Open Slow Configuration Block on-board (SYS16-B03 = 0).
0609 Your OPC09 must be zero because FOC is invalid (SYS16-B00 = 0).
0610 Your OPC10 must be zero because FOC is invalid (SYS16-B00 = 0).
0611 Your OPC11 must be zero because FOC is invalid (SYS16-B00 = 0).
0612 Your OPC12 must be zero because FOC is invalid (SYS16-B00 = 0).
0613 Your OPC13 must be zero because FOC is invalid (SYS16-B00 = 0).
0614 Your OPC14 must be zero because FOC is invalid (SYS16-B00 = 0).
0615 Your OPC15 must be zero because FOC is invalid (SYS16-B00 = 0).
0616 Your OPC16 must be zero because FOC is invalid (SYS16-B00 = 0).
0617 Your OPC17 must be zero because FOC is invalid (SYS16-B00 = 0).
0618 Your OPC18 must be zero because SOC is invalid (SYS16-B01 = 0).
0619 Your OPC19 must be zero because SOC is invalid (SYS16-B01 = 0).
0620 Your OPC20 must be zero because SOC is invalid (SYS16-B01 = 0).
0621 Your OPC21 must be zero because SOC is invalid (SYS16-B01 = 0).
0622 Your OPC22 must be zero because SOC is invalid (SYS16-B01 = 0).
0623 Your OPC23 must be zero because SOC is invalid (SYS16-B01 = 0).
0624 Your OPC24 must be zero because SOC is invalid (SYS16-B01 = 0).
0625 Your OPC25 must be zero because SOC is invalid (SYS16-B01 = 0).
0626 Your OPC26 must be zero because SOC is invalid (SYS16-B01 = 0).
0627 Your OPC27 must be zero because TOC is invalid (SYS16-B02 = 0).
0628 Your OPC28 must be zero because TOC is invalid (SYS16-B02 = 0).
0629 Your OPC29 must be zero because TOC is invalid (SYS16-B02 = 0).
0630 Your OPC30 must be zero because TOC is invalid (SYS16-B02 = 0).
0631 Your OPC31 must be zero because TOC is invalid (SYS16-B02 = 0).
0632 Your OPC32 must be zero because TOC is invalid (SYS16-B02 = 0).
