User Manual

4–47Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 21
0430 OPC30 is out of range. When OPC03-B14 = 1, a non-zero entry for OPC30 must be within
TOC45
≤ OPC30 ≤ TOC46
0431 OPC31 is out of range.
If non-zero, OPC31 must be within TOC41
≤ OPC31 ≤ TOC42
0432 OPC32 is out of range.
if: then:
MCC27 and MCC28 OPC32 must be within 00000 ≤ OPC32 ≤ MCC28 – MCC27
are both non-zero
MCC27 is non-zero and OPC32 must be within 00000 ≤ OPC32 ≤ MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and OPC32 must be within 00000 ≤ OPC32 ≤ MCC28 – MCC23.
MCC28 is non-zero
MCC27 and MCC28 OPC32 must be within 00000 ≤ OPC32 ≤ MCC24 – MCC23
are both zero
0433 OPC33 is out of range. When OPC03-B14 = 1, a non-zero entry for OPC33 must be within
TOC45
≤ OPC33 ≤ TOC46
0434 OPC34 is out of range.
If non-zero, OPC34 must be within TOC41
≤ OPC34 ≤ TOC42
0435 OPC35 is out of range.
if: then:
MCC27 and MCC28 OPC35 must be within 00000 ≤ OPC35 ≤ MCC28 – MCC27
are both non-zero
MCC27 is non-zero and OPC35 must be within 00000 ≤ OPC35 ≤ MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and OPC35 must be within 00000 ≤ OPC35 ≤ MCC28 – MCC23
MCC28 is non-zero
MCC27 and MCC28 OPC35 must be within 00000 ≤ OPC3 ≤ MCC24 – MCC23
are both zero
0436 OPC36 is out of range. When OPC03-B14 = 1, a non-zero entry for OPC36 must be within
OSC45
≤ OPC36 ≤ OSC46
0437 OPC37 is out of range.
If non-zero, OPC37 must be within OSC41
≤ OPC37 ≤ OSC42
0438 OPC38 is out of range.
if: then:
MCC27 and MCC28 OPC38 must be within 00000 ≤ OPC38 ≤ MCC28 – MCC27
are both non-zero
MCC27 is non-zero and OPC38 must be within 00000 ≤ OPC38 ≤ MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and OPC38 must be within 00000 ≤ OPC3 ≤ MCC28 – MCC23.
MCC28 is non-zero
MCC27 and MCC28 OPC38 must be within 00000 ≤ OPC3 ≤ MCC24 – MCC23
are both zero
0439 OPC39 is out of range. When OPC03-B14 = 1, a non-zero entry for OPC39 must be within
OSC45
≤ OPC39 ≤ OSC46
0440 OPC40 is out of range.
If non-zero, OPC40 must be within OSC41
≤ OPC40 ≤ OSC42
0461
OPC61 is out of range. Valid range is 00000 ≤ OPC61 < OPC62
0462 OPC62 is out of range.
if: then:
MCC27 and MCC28 OPC62 must be within OPC61 < OPC62 ≤ MCC28 – MCC27
are both non-zero
MCC27 is non-zero and OPC62 must be within OPC61 < OPC62 ≤ MCC24 – MCC27.
MCC28 is zero
