4–46 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 21
0419 OPC19 is out of range.
If non-zero, OPC19 must be within SOC41
≤ OPC19 ≤ SOC42
0420 OPC20 is out of range.
if: then:
MCC27 and MCC28 OPC20 must be within 00000 ≤ OPC20 ≤ MCC28 – MCC27
are both non-zero
MCC27 is non-zero and OPC20 must be within 00000 ≤ OPC20 ≤ MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and OPC20 must be within 00000 ≤ OPC20 ≤ MCC28 – MCC23.
MCC28 is non-zero
MCC27 and MCC28 OPC20 must be within 00000 ≤ OPC20 ≤ MCC24 – MCC23
are both zero
0421 OPC21 is out of range. When OPC03-B14 = 1, a non-zero entry for OPC21 must be within
SOC45
≤ OPC21 ≤ SOC46
0422 OPC22 is out of range.
If non-zero, OPC22 must be within SOC41
≤ OPC22 ≤ SOC42
0423 OPC23 is out of range.
if: then:
MCC27 and MCC28 OPC23 must be within 00000 ≤ OPC23 ≤ MCC28 – MCC27
are both non-zero
MCC27 is non-zero and OPC23 must be within 00000 ≤ OPC23 ≤ MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and OPC23 must be within 00000 ≤ OPC23 ≤ MCC28 – MCC23.
MCC28 is non-zero
MCC27 and MCC28 OPC23 must be within 00000 ≤ OPC23 ≤ MCC24 – MCC23
are both zero
0424 OPC24 is out of range. When OPC03-B14 = 1, a non-zero entry for OPC24 must be within
SOC45
≤ OPC24 ≤ SOC46
0425 OPC25 is out of range.
If non-zero, OPC25 must be within SOC41
≤ OPC25 ≤ SOC42
0426 OPC26 is out of range.
if: then:
MCC27 and MCC28 OPC26 must be within 00000 ≤ OPC26 ≤ MCC28 – MCC27
are both non-zero
MCC27 is non-zero and OPC26 must be within 00000 ≤ OPC26 ≤ MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and OPC26 must be within 00000 ≤ OPC26 ≤ MCC28 – MCC23
MCC28 is non-zero
MCC27 and MCC28 OPC26 must be within 00000 ≤ OPC26 ≤ MCC24 – MCC23
are both zero
0427 OPC27 is out of range. When OPC03-B14 = 1, a non-zero entry for OPC27 must be within
TOC45
≤ OPC27 ≤ TOC46
0428 OPC28 is out of range.
If non-zero, OPC28 must be within TOC41
≤ OPC28 ≤ TOC42
0429 OPC29 is out of range.
if: then:
MCC27 and MCC28 OPC29 must be within 00000 ≤ OPC29 ≤ MCC28 – MCC27
are both non-zero
MCC27 is non-zero and OPC29 must be within 00000 ≤ OPC29 ≤ MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and OPC29 must be within 00000 ≤ OPC29 ≤ MCC28 – MCC23
MCC28 is non-zero
MCC27 and MCC28 OPC29 must be within 00000 ≤ OPC29 ≤ MCC24 – MCC23
are both zero
