User Manual

4–44 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 20
0231
OSC31 is out of range. Valid range is 00000 ≤ OSC31 ≤ 09999
0232
OSC32 is out of range. Valid range is 00000 ≤ OSC32 ≤ 09999
0233
OSC33 is out of range. Valid range is 00000 ≤ OSC33 ≤ 09999
0234
OSC34 is out of range. Valid range is 00000 ≤ OSC34 ≤ 09999
0235
OSC35 is out of range. Valid range is 00000 ≤ OSC35 ≤ 09999
0236
OSC36 is out of range. Valid range is 00000 ≤ OSC36 ≤ 09999
0237
OSC37 is out of range. Valid range is 00000 ≤ OSC37 ≤ 09999
0238
OSC38 is out of range. Valid range is 00000 ≤ OSC38 ≤ 09999
0239
OSC39 is out of range. Valid range is 00000 ≤ OSC39 ≤ 09999
0240
OSC40 is out of range. Valid range is 00000 ≤ OSC40 ≤ 09999
0243
OSC43 is out of range. Valid range is 00000 ≤ OSC43 ≤ 09999
0244
OSC44 is out of range. Valid range is 00000 ≤ OSC44 ≤ 09999
0247
OSC47 is out of range. Valid range is 00000 ≤ OSC47 ≤ 09999
0248
OSC48 is out of range. Valid range is 00000 ≤ OSC48 ≤ 09999
0249
OSC49 is out of range. Valid range is 00000 ≤ OSC49 ≤ 09999
0250
OSC50 is out of range. Valid range is 00000 ≤ OSC50 ≤ 09999
0251
OSC51 is out of range. Valid range is 00000 ≤ OSC51 ≤ 09999
0252
OSC52 is out of range. Valid range is 00000 ≤ OSC52 ≤ 09999
0253
OSC53 is out of range. Valid range is 00000 ≤ OSC53 ≤ 09999
0343 OSC43 is equal to OSC44. They must not be equal.
0347 OSC47 is equal to OSC48. They must not be equal.
0441
OSC41 is out of range. Valid range is 00000 ≤ OSC41 < OSC42
0442
OSC42 is out of range. Valid range is OSC41 < OSC42 ≤ 09999
0445
OSC45 is out of range. Valid range is 00000 ≤ OSC45 < OSC46
0446
OSC46 is out of range. Valid range is OSC45 < OSC46 ≤ 09999
0457 OSC57 is out of range.
If non-zero, OSC57 must be within MCC31 < OSC57
≤ MCC32
0502 Your bit pattern in OSC02-B02, OSC02-B01, and OSC02-B00 indicates a selected clamp
velocity control valve that is unconnected according to your entries in MCC02 and MCC04.
0506 Your bit pattern in OSC02-B06, OSC02-B05, and OSC02-B04 indicates a selected clamp
pressure control valve that is unconnected according to your entries in MCC02 and MCC04.
ID = 21 OPC – Clamp Open Profile Block
Error Code
Description ID = 21
0209 OPC09 is out of range.
When OPC03-B14 = 0, OPC09 must be within 00000
≤ OPC09 ≤ 09999
0212 OPC12 is out of range.
When OPC03-B14 = 0, OPC12 must be within 00000
≤ OPC12 ≤ 09999
0215 OPC15 is out of range.
When OPC03-B14 = 0, OPC15 must be within 00000
≤ OPC15 ≤ 09999
0218 OPC18 is out of range.
When OPC03-B14 = 0, OPC18 must be within 00000
≤ OPC18 ≤ 09999
0221 OPC21 is out of range.
When OPC03-B14 = 0, OPC21 must be within 00000
≤ OPC21 ≤ 09999
0224 OPC24 is out of range.
0224
OPC24
is
out
of
range
.
When OPC03-B14 = 0, OPC24 must be within 00000
≤ OPC24 ≤ 09999
0227 OPC27 is out of range.
When OPC03-B14 = 0, OPC27 must be within 00000
≤ OPC27 ≤ 09999
