User Manual

4–43Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 19
0248
TOC48 is out of range. Valid range is 00000 ≤ TOC48 ≤ 09999
0249
TOC49 is out of range. Valid range is 00000 ≤ TOC49 ≤ 09999
0250
TOC50 is out of range. Valid range is 00000 ≤ TOC50 ≤ 09999
0251
TOC51 is out of range. Valid range is 00000 ≤ TOC51 ≤ 09999
0252
TOC52 is out of range. Valid range is 00000 ≤ TOC52 ≤ 09999
0253
TOC53 is out of range. Valid range is 00000 ≤ TOC53 ≤ 09999
0343 TOC43 is equal to TOC44. They must not be equal.
0347 TOC47 is equal to TOC48. They must not be equal.
0441
TOC41 is out of range. Valid range is 00000 ≤ TOC41 < TOC42
0442
TOC42 is out of range. Valid range is TOC41 < TOC42 ≤ 09999
0445
TOC45 is out of range. Valid range is 00000 ≤ TOC45 < TOC46
0446
TOC46 is out of range. Valid range is TOC45 < TOC46 ≤ 09999
0457 TOC57 is out of range.
If non-zero, TOC57 must be within MCC31 < TOC57
≤ MCC32
0502 Your bit pattern in TOC02-B02, TOC02-B01, and TOC02-B00 indicates a selected clamp
velocity control valve that is unconnected according to your entries in MCC02 and MCC04.
0506 Your bit pattern in TOC02-B06, TOC02-B05, and TOC02-B04 indicates a selected clamp
pressure control valve that is unconnected according to your entries in MCC02 and MCC04.
ID = 20 OSC – Clamp Open Slow Configuration Block
Error Code
Description ID = 20
0205
OSC05 is out of range. Valid range is 00000 ≤ OSC05 ≤ 09999
0206
OSC06 is out of range. Valid range is 00000 ≤ OSC06 ≤ 09999
0208
OSC08 is out of range. Valid range is 00000 ≤ OSC08 ≤ 09999
0209
OSC09 is out of range. Valid range is 00000 ≤ OSC09 ≤ 09999
0210
OSC10 is out of range. Valid range is 00000 ≤ OSC10 ≤ 09999
0211
OSC11 is out of range. Valid range is 00000 ≤ OSC11 ≤ 09999
0212
OSC12 is out of range. Valid range is 00000 ≤ OSC12 ≤ 09999
0213
OSC13 is out of range. Valid range is 00000 ≤ OSC13 ≤ 09999
0214
OSC14 is out of range. Valid range is 00000 ≤ OSC14 ≤ 09999
0215
OSC15 is out of range. Valid range is 00000 ≤ OSC15 ≤ 09999
0216
OSC16 is out of range. Valid range is 00000 ≤ OSC16 ≤ 09999
0217
OSC17 is out of range. Valid range is 00000 ≤ OSC17 ≤ 09999
0218
OSC18 is out of range. Valid range is 00000 ≤ OSC18 ≤ 09999
0219
OSC19 is out of range. Valid range is 00000 ≤ OSC19 ≤ 09999
0220
OSC20 is out of range. Valid range is 00000 ≤ OSC20 ≤ 09999
0221
OSC21 is out of range. Valid range is 00000 ≤ OSC21 ≤ 09999
0222
OSC22 is out of range. Valid range is 00000 ≤ OSC22 ≤ 09999
0223
OSC23 is out of range. Valid range is 00000 ≤ OSC23 ≤ 09999
0224
OSC24 is out of range. Valid range is 00000 ≤ OSC24 ≤ 09999
0225
OSC25 is out of range. Valid range is 00000 ≤ OSC25 ≤ 09999
0226
OSC26 is out of range. Valid range is 00000 ≤ OSC26 ≤ 09999
0227
OSC27 is out of range. Valid range is 00000 ≤ OSC27 ≤ 09999
0228
OSC28 is out of range. Valid range is 00000 ≤ OSC28 ≤ 09999
0229
OSC29 is out of range. Valid range is 00000 ≤ OSC29 ≤ 09999
0230
OSC30 is out of range. Valid range is 00000 ≤ OSC30 ≤ 09999
