4–42 Programming Error Codes
Publication
1771-6.5.88 – July 1997
Error Code
Description
ID = 18
0502 Your bit pattern in SOC02-B02, SOC02-B01, and SOC02-B00 indicates a selected clamp
velocity control valve that is unconnected according to your entries in MCC02 and MCC04.
0506 Your bit pattern in SOC02-B06, SOC02-B05, and SOC02-B04 indicates a selected clamp
pressure control valve that is unconnected according to your entries in MCC02 and MCC04.
ID = 19
TOC – Third Clamp Open Configuration Block
Error Code
Description
ID = 19
0205
TOC05 is out of range. Valid range is 00000
≤
TOC05
≤
09999
0206
TOC06 is out of range. Valid range is 00000
≤
TOC06
≤
09999
0208
TOC08 is out of range. Valid range is 00000
≤
TOC08
≤
09999
0209
TOC09 is out of range. Valid range is 00000
≤
TOC09
≤
09999
0210
TOC10 is out of range. Valid range is 00000
≤
TOC10
≤
09999
0211
TOC11 is out of range. Valid range is 00000
≤
TOC11
≤
09999
0212
TOC12 is out of range. Valid range is 00000
≤
TOC12
≤
09999
0213
TOC13 is out of range. Valid range is 00000
≤
TOC13
≤
09999
0214
TOC14 is out of range. Valid range is 00000
≤
TOC14
≤
09999
0215
TOC15 is out of range. Valid range is 00000
≤
TOC15
≤
09999
0216
TOC16 is out of range. Valid range is 00000
≤
TOC16
≤
09999
0217
TOC17 is out of range. Valid range is 00000
≤
TOC17
≤
09999
0218
TOC18 is out of range. Valid range is 00000
≤
TOC18
≤
09999
0219
TOC19 is out of range. Valid range is 00000
≤
TOC19
≤
09999
0220
TOC20 is out of range. Valid range is 00000
≤
TOC20
≤
09999
0221
TOC21 is out of range. Valid range is 00000
≤
TOC21
≤
09999
0222
TOC22 is out of range. Valid range is 00000
≤
TOC22
≤
09999
0223
TOC23 is out of range. Valid range is 00000
≤
TOC23
≤
09999
0224
TOC24 is out of range. Valid range is 00000
≤
TOC24
≤
09999
0225
TOC25 is out of range. Valid range is 00000
≤
TOC25
≤
09999
0226
TOC26 is out of range. Valid range is 00000
≤
TOC26
≤
09999
0227
TOC27 is out of range. Valid range is 00000
≤
TOC27
≤
09999
0228
TOC28 is out of range. Valid range is 00000
≤
TOC28
≤
09999
0229
TOC29 is out of range. Valid range is 00000
≤
TOC29
≤
09999
0230
TOC30 is out of range. Valid range is 00000
≤
TOC30
≤
09999
0231
TOC31 is out of range. Valid range is 00000
≤
TOC31
≤
09999
0232
TOC32 is out of range. Valid range is 00000
≤
TOC32
≤
09999
0233
TOC33 is out of range. Valid range is 00000
≤
TOC33
≤
09999
0234
TOC34 is out of range. Valid range is 00000
≤
TOC34
≤
09999
0235
TOC35 is out of range. Valid range is 00000
≤
TOC35
≤
09999
0236
TOC36 is out of range. Valid range is 00000
≤
TOC36
≤
09999
0237
TOC37 is out of range. Valid range is 00000
≤
TOC37
≤
09999
0238
TOC38 is out of range. Valid range is 00000
≤
TOC38
≤
09999
0239
TOC39 is out of range. Valid range is 00000
≤
TOC39
≤
09999
0240
TOC40 is out of range. Valid range is 00000
≤
TOC40
≤
09999
0243
TOC43 is out of range. Valid range is 00000
≤
TOC43
≤
09999
0244
TOC44 is out of range. Valid range is 00000
≤
TOC44
≤
09999
0247
TOC47 is out of range. Valid range is 00000
≤
TOC47
≤
09999
