User Manual

4–40 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 17
0228
FOC28 is out of range. Valid range is 00000 ≤ FOC28 ≤ 09999
0229
FOC29 is out of range. Valid range is 00000 ≤ FOC29 ≤ 09999
0230
FOC30 is out of range. Valid range is 00000 ≤ FOC30 ≤ 09999
0231
FOC31 is out of range. Valid range is 00000 ≤ FOC31 ≤ 09999
0232
FOC32 is out of range. Valid range is 00000 ≤ FOC32 ≤ 09999
0233
FOC33 is out of range. Valid range is 00000 ≤ FOC33 ≤ 09999
0234
FOC34 is out of range. Valid range is 00000 ≤ FOC34 ≤ 09999
0235
FOC35 is out of range. Valid range is 00000 ≤ FOC35 ≤ 09999
0236
FOC36 is out of range. Valid range is 00000 ≤ FOC36 ≤ 09999
0237
FOC37 is out of range. Valid range is 00000 ≤ FOC37 ≤ 09999
0238
FOC38 is out of range. Valid range is 00000 ≤ FOC38 ≤ 09999
0239
FOC39 is out of range. Valid range is 00000 ≤ FOC39 ≤ 09999
0240
FOC40 is out of range. Valid range is 00000 ≤ FOC40 ≤ 09999
0243
FOC43 is out of range. Valid range is 00000 ≤ FOC43 ≤ 09999
0244
FOC44 is out of range. Valid range is 00000 ≤ FOC44 ≤ 09999
0247
FOC47 is out of range. Valid range is 00000 ≤ FOC47 ≤ 09999
0248
FOC48 is out of range. Valid range is 00000 ≤ FOC48 ≤ 09999
0249
FOC49 is out of range. Valid range is 00000 ≤ FOC49 ≤ 09999
0250
FOC50 is out of range. Valid range is 00000 ≤ FOC50 ≤ 09999
0251
FOC51 is out of range. Valid range is 00000 ≤ FOC51 ≤ 09999
0252
FOC52 is out of range. Valid range is 00000 ≤ FOC52 ≤ 09999
0253
FOC53 is out of range. Valid range is 00000 ≤ FOC53 ≤ 09999
0343 FOC43 is equal to FOC44. They must not be equal.
0347 FOC47 is equal to FOC48. They must not be equal.
0441
FOC41 is out of range. Valid range is 00000 ≤ FOC41 < FOC42
0442
FOC42 is out of range. Valid range is TOC41 < FOC42 ≤ 09999
0445
FOC45 is out of range. Valid range is 00000 ≤ FOC45 < FOC46
0446
FOC46 is out of range. Valid range is FOC45 < FOC46 ≤ 09999
0457 FOC57 is out of range.
If non-zero, FOC57 must be within MCC31 < FOC57
≤ MCC32
0502 Your bit pattern in FOC02-B02, FOC02-B01, and FOC02-B00 indicates a selected clamp
velocity control valve that is unconnected according to your entries in MCC02 and MCC04.
0506 Your bit pattern in FOC02-B06, FOC02-B05, and FOC02-B04 indicates a selected clamp
pressure control valve that is unconnected according to your entries in MCC02 and MCC04.
ID = 18 SOC – Second Clamp Open Configuration Block
Error Code
Description ID = 18
0205
SOC05 is out of range. Valid range is 00000 ≤ SOC05 ≤ 09999
0206
SOC06 is out of range. Valid range is SOC06 ≤ SOC06 ≤ 09999
0208
SOC08 is out of range. Valid range is 00000 ≤ SOC08 ≤ 09999
0209
SOC09 is out of range. Valid range is 00000 ≤ SOC09 ≤ 09999
0210
SOC10 is out of range. Valid range is 00000 ≤ SOC10 ≤ 09999
0211
SOC11 is out of range. Valid range is 00000 ≤ SOC11 ≤ 09999
0212
SOC12 is out of range. Valid range is 00000 ≤ SOC12 ≤ 09999
0213
SOC13 is out of range. Valid range is 00000 ≤ SOC13 ≤ 09999
0214
SOC14 is out of range. Valid range is 00000 ≤ SOC14 ≤ 09999
