User Manual

4–39Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 16
0240
PSC40 is out of range. Valid range is 00000 ≤ PSC40 ≤ 09999
0405 PSC05 is out of range.
if: then:
MCC13 and MCC14 PSC05 must be within 00000 ≤ PSC05 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PSC05 must be within 00000 ≤ PSC05 ≤ MCC10 – MCC13
MCC14 is zero
MCC13 is zero and PSC05 must be within 00000 ≤ PSC05 ≤ MCC14 – MCC09
MCC14 is non-zero
MCC13 and MCC14 PSC05 must be within 00000 ≤ PSC05 ≤ MCC10 – MCC09
are both zero
0457 PSC57 is out of range.
If non-zero, PSC57 must be within MCC17 < PSC57
≤ MCC18
0905 PSC05 is too large.
if: then:
MCC13 and MCC14 PSC05 must be within MCC13 + PPC61 + PPC62 + PSC05
are both non-zero ≤ MCC14
MCC13 is zero and PSC05 must be within MCC09 + PPC61 + PPC62 + PSC05
MCC14 is non-zero ≤ MCC14
MCC13 is non-zero and PSC05 must be within MCC13 + PPC61 + PPC62 + PSC05
MCC14 is zero ≤ MCC10
MCC13 and MCC14 PSC05 must be within MCC09 + PPC61 + PPC62 + PSC05
are both zero ≤ MCC10
ID = 17 FOC – First Clamp Open Configuration Block
Error Code
Description ID = 17
0205
FOC05 is out of range. Valid range is 00000 ≤ FOC05 ≤ 09999
0206
FOC06 is out of range. Valid range is 00000 ≤ FOC06 ≤ 09999
0208
FOC08 is out of range. Valid range is 00000 ≤ FOC08 ≤ 09999
0209
FOC09 is out of range. Valid range is 00000 ≤ FOC09 ≤ 09999
0210
FOC10 is out of range. Valid range is 00000 ≤ FOC10 ≤ 09999
0211
FOC11 is out of range. Valid range is 00000 ≤ FOC11 ≤ 09999
0212
FOC12 is out of range. Valid range is 00000 ≤ FOC12 ≤ 09999
0213
FOC13 is out of range. Valid range is 00000 ≤ FOC13 ≤ 09999
0214
FOC14 is out of range. Valid range is 00000 ≤ FOC14 ≤ 09999
0215
FOC15 is out of range. Valid range is 00000 ≤ FOC15 ≤ 09999
0216
FOC16 is out of range. Valid range is 00000 ≤ FOC16 ≤ 09999
0217
FOC17 is out of range. Valid range is 00000 ≤ FOC17 ≤ 09999
0218
FOC18 is out of range. Valid range is 00000 ≤ FOC18 ≤ 09999
0219
FOC19 is out of range. Valid range is 00000 ≤ FOC19 ≤ 09999
0220
FOC20 is out of range. Valid range is 00000 ≤ FOC20 ≤ 09999
0221
FOC21 is out of range. Valid range is 00000 ≤ FOC21 ≤ 09999
0222
FOC22 is out of range. Valid range is 00000 ≤ FOC22 ≤ 09999
0223
FOC23 is out of range. Valid range is 00000 ≤ FOC23 ≤ 09999
0224
FOC24 is out of range. Valid range is 00000 ≤ FOC24 ≤ 09999
0225
FOC25 is out of range. Valid range is 00000 ≤ FOC25 ≤ 09999
0226
FOC26 is out of range. Valid range is 00000 ≤ FOC26 ≤ 09999
0227
FOC27 is out of range. Valid range is 00000 ≤ FOC27 ≤ 09999
