4–36 Programming Error Codes
Publication
1771-6.5.88 – July 1997
Error Code
Description
ID = 15
0461 PPC61 is out of range.
if: then:
MCC13 and MCC14 PPC61 must be within 00000
≤
PPC61
≤
MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PPC61 must be within 00000
≤
PPC61
≤
MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and PPC61 must be within 00000
≤
PPC61
≤
MCC14 – MCC09
MCC14 is non-zero .
MCC13 and MCC14 PPC61 must be within 00000
≤
PPC61
≤
MCC10 – MCC09
are both zero
0462 PPC62 is out of range.
if: then:
MCC13 and MCC14 PPC62 must be within 00000
≤
PPC62
≤
MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PPC62 must be within 00000
≤
PPC62
≤
MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and PPC62 must be within 00000
≤
PPC62
≤
MCC14 – MCC09
MCC14 is non-zero
MCC13 and MCC14 PPC62 must be within 00000
≤
PPC62
≤
MCC10 – MCC09
are both zero
0503 You have selected RPM/Pos execution of the Plastication profile by PPC03-B01 = 1 and
PPC03 -B00 = 0, but your bit pattern in MCC02 indicates that the QDC module is not config-
ured for connection of a screw RPM sensor.
0504 You have selected closed-loop Press/Pos execution for the Plastication Profile by PPC04-B00
= 0, but your bit patterns in MCC02 and MCC03 indicate that the QDC module is not con-
nected to a ram (screw) pressure transducer.
0507 You have selected RPM/Time execution of the Plastication profile by PPC03-B01 = 1 and
PPC03-B00 = 1, but your bit pattern in MCC02 indicates that the QDC module is not config-
ured for connection of a screw RPM sensor.
0508 You have selected closed-loop Press/Time execution of the Plastication Profile by PPC04-B01
= 0, but your bit patterns in MCC02 and MCC03 indicate that the QDC module is not con-
nected to a ram (screw) pressure transducer.
0512 You have selected closed-loop RPM/Pos execution of the Plastication profile by PPC04-B02 =
0, but your bit patterns in MCC02 and MCC03 indicate that the QDC module is not connected
to a screw RPM sensor.
0516 You have selected closed-loop RPM/Time execution of the Plastication profile by PPC04-B03
= 0, but your bit patterns in MCC02 and MCc03 indicate that the QDC module is not con-
nected to a screw RPM sensor.
0600 Your entire Plastication Profile Command Block has been rejected because the QDC module
module does not have a valid Plastication Configuration Command Block on-board
(SYS15-B13 = 0).
0711 PPC11 cannot be 00000 when PPC14 > 00000.
0712 PPC12 cannot be 00000 when PPC14 > 00000.
0715 PPC15 cannot be 00000 when PPC18 > 00000.
0716 PPC16 cannot be 00000 when PPC18 > 00000.
0719 PPC19 cannot be 00000 when PPC22 > 00000.
0720 PPC20 cannot be 00000 when PPC22 > 00000.
0723 PPC23 cannot be 00000 when PPC26 > 00000.
0724 PPC24 cannot be 00000 when PPC26 > 00000.
0727 PPC27 cannot be 00000 when PPC30 > 00000.
0728 PPC28 cannot be 00000 when PPC30 > 00000.
0731 PPC31 cannot be 00000 when PPC34 > 00000.
0732 PPC32 cannot be 00000 when PPC34 > 00000.
0735 PPC35 cannot be 00000 when PPC38 > 00000.
