1–8 Abbreviated Command and Status Blocks
Publication
1771-6.5.88 – July 1997
Deceleration Ramp Rates
ERC25
N45:81 Output #1
ERC26 N45:82 Output #2
ERC27 N45:83 Output #3
ERC28 N45:84 Output #4
ERC29 N45:85 Output #5
ERC30 N45:86 Output #6
ERC31 N45:87 Output #7
ERC32 N45:88 Output #8
End of Stroke Set-output Values
ERC33 N45:89 Output #1
ERC34 N45:90 Output #2
ERC35 N45:91 Output #3
ERC36 N45:92 Output #4
ERC37 N45:93 Output #5
ERC38 N45:94 Output #6
ERC39 N45:95 Output #7
ERC40 N45:96 Output #8
Pressure Control Limits
ERC41 N45:97 Minimum limit
ERC42 N45:98 Maximum limit
ERC43 N45:99 % output for minimum
ERC44 N45:100 % output for maximum
Velocity Control Limits
ERC45 N45:101 Minimum limit
ERC46 N45:102 Maximum limit
ERC47 N45:103 % output for minimum
ERC48 N45:104 % output for maximum
Retract Stroke Tuning Constants
ERC49 N45:105 Proportional gain, pressure control
ERC50 N45:106 Integral gain, pressure control
ERC51 N45:107 Derivative gain, pressure control
ERC52 N45:108 Proportional gain, velocity control
ERC53 N45:109 Feedforward gain, velocity control
ERC54-64 N45:110-120 RFU
Word Pro-Set Address Description
Bit-mapped Control Words
FCC01 B37:0 Block ID 00000000 00000011
FCC02 B37:1 Selected valve configurations
FCC03-04 B37:2-3 RFU
Expert Compensation Response Percentage
FCC05 N43:1 ERC % minimum velocity
FCC06 N43:2 ERC % minimum pressure
FCC07 N43:3 RFU
Watchdog Timer
FCC08 N43:4 Profile watchdog timer
FCC – First Clamp Close
Configuration Block
