User Manual

4–35Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 15
0435 PPC35 is out of range.
if: then:
MCC13 and MCC14 PPC35 must be within 00000 ≤ PPC35 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PPC35 must be within 00000 ≤ PPC35 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and PPC35 must be within 00000 ≤ PPC35 ≤ MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 PPC35 must be within 00000 ≤ PPC35 ≤ MCC10 – MCC09
are both zero
0438 PPC38 is out of range.
If non-zero, PPC38 must be within PLC41
≤ PPC38 ≤ PLC42
0439 PPC39 is out of range.
if: then:
MCC13 and MCC14 PPC39 must be within 00000 ≤ PPC39 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PPC39 must be within 00000 ≤ PPC39 ≤ MCC10 – MCC13
MCC14 is zero
MCC13 is zero and PPC39 must be within 00000 ≤ PPC39 ≤ MCC14 – MCC09
MCC14 is non-zero .
MCC13 and MCC14 PPC39 must be within 00000 ≤ PPC39 ≤ MCC10 – MCC09
are both zero
0442 PPC42 is out of range.
If non-zero, PPC42 must be within PLC41
≤ PPC42 ≤ PLC42
0443 PPC43 is out of range.
if: then:
MCC13 and MCC14 PPC43 must be within 00000 ≤ PPC43 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PPC43 must be within 00000 ≤ PPC43 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and PPC43 must be within 00000 ≤ PPC43 ≤ MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 PPC43 must be within 00000 ≤ PPC43 ≤ MCC10 – MCC09
are both zero
0446 PPC46 is out of range.
If non-zero, PPC46 must be within PLC41
≤ PPC46 ≤ PLC42
0447 PPC47 is out of range.
if: then:
MCC13 and MCC14 PPC47 must be within 00000 ≤ PPC47 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PPC47 must be within 00000 ≤ PPC47 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and PPC47 must be within 00000 ≤ PPC47 ≤ MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 PPC47 must be within 00000 ≤ PPC47 ≤ MCC10 – MCC09
are both zero
0450 PPC50 is out of range.
If non-zero, PPC50 must be within PLC41
≤ PPC50 ≤ PLC42
0452
PPC52 is out of range. Valid range is 00000 ≤ PPC52 ≤ PLC42
