User Manual

4–34 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 15
0419 PPC19 is out of range.
if: then:
MCC13 and MCC14 PPC19 must be within 00000 ≤ PPC19 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PPC19 must be within 00000 ≤ PPC19 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and PPC19 must be within 00000 ≤ PPC19 ≤ MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 PPC19 must be within 00000 ≤ PPC19 ≤ MCC10 – MCC09
are both zero
0422 PPC22 is out of range.
If non-zero, PPC22 must be within PLC41
≤ PPC22 ≤ PLC42
0423 PPC23 is out of range.
if: then:
MCC13 and MCC14 PPC23 must be within 00000 ≤ PPC23 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PPC23 must be within 00000 ≤ PPC23 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and PPC23 must be within 00000 ≤ PPC23 ≤ MCC14 – MCC09
MCC14 is non-zero .
MCC13 and MCC14 PPC23 must be within 00000 ≤ PPC23 ≤ MCC10 – MCC09
are both zero
0426 PPC26 is out of range.
If non-zero, PPC26 must be within PLC41
≤ PPC26 ≤ PLC42
0427 PPC27 is out of range.
if: then:
MCC13 and MCC14 PPC27 must be within 00000 ≤ PPC27 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PPC27 must be within 00000 ≤ PPC27 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and PPC27 must be within 00000 ≤ PPC27 ≤ MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 PPC27 must be within 00000 ≤ PPC27 ≤ MCC10 – MCC09
are both zero
0430 PPC30 is out of range.
If non-zero, PPC30 must be within PLC41
≤ PPC30 ≤ PLC42
0431 PPC31 is out of range.
if: then:
MCC13 and MCC14 PPC31 must be within 00000 ≤ PPC31 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PPC31 must be within 00000 ≤ PPC31 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and PPC31 must be within 00000 ≤ PPC31 ≤ MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 PPC31 must be within 00000 ≤ PPC31 ≤ MCC10 – MCC09
are both zero
0434 PPC34 is out of range.
If non-zero, PPC34 must be within PLC41
≤ PPC34 ≤ PLC42
