4–33Programming Error Codes
Publication 1771-6.5.88 – July 1997
ID = 15 PPC – Plastication Profile Block
Error Code
Description ID = 15
0209
PPC09 is out of range. Valid range is 00000 ≤ PPC09 ≤ 09999
0212
PPC12 is out of range. Valid range is 00000 ≤ PPC12 ≤ 09999
0213
PPC13 is out of range. Valid range is 00000 ≤ PPC13 ≤ 09999
0216
PPC16 is out of range. Valid range is 00000 ≤ PPC16 ≤ 09999
0217
PPC17 is out of range. Valid range is 00000 ≤ PPC17 ≤ 09999
0220
PPC20 is out of range. Valid range is PPC20 ≤ PPC20 ≤ 09999
0221
PPC21 is out of range. Valid range is PPC20 ≤ PPC21 ≤ 09999
0224
PPC24 is out of range. Valid range is 00000 ≤ PPC24 ≤ 09999
0225
PPC25 is out of range. Valid range is 00000 ≤ PPC25 ≤ 09999
0228
PPC28 is out of range. Valid range is 00000 ≤ PPC28 ≤ 09999
0229
PPC29 is out of range. Valid range is 00000 ≤ PPC29 ≤ 09999
0232
PPC32 is out of range. Valid range is 00000 ≤ PPC32 ≤ 09999
0233
PPC33 is out of range. Valid range is 00000 ≤ PPC33 ≤ 09999
0236
PPC36 is out of range. Valid range is 00000 ≤ PPC36 ≤ 09999
0237
PPC37 is out of range. Valid range is 00000 ≤ PPC37 ≤ 09999
0240
PPC40 is out of range. Valid range is PPC40 ≤ PPC40 ≤ 09999
0241
PPC41 is out of range. Valid range is PPC41 ≤ PPC40 ≤ 09999
0244
PPC44 is out of range. Valid range is 00000 ≤ PPC44 ≤ 09999
0245
PPC45 is out of range. Valid range is 00000 ≤ PPC45 ≤ 09999
0248
PPC48 is out of range. Valid range is 00000 ≤ PPC48 ≤ 09999
0249
PPC49 is out of range. Valid range is 00000 ≤ PPC49 ≤ 09999
0251
PPC51 is out of range. Valid range is 00000 ≤ PPC51 ≤ 09999
0410 PPC10 is out of range.
If non-zero, PPC10 must be within PLC41
≤ PPC10 ≤ PLC42
0411 PPC11 is out of range.
if: then:
MCC13 and MCC14 PPC11 must be within 00000 ≤ PPC11 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PPC11 must be within 00000 ≤ PPC11 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and PPC11 must be within 00000 ≤ PPC11 ≤ MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 PPC11 must be within 00000 ≤ PPC11 ≤ MCC10 – MCC09
are both zero
0414 PPC14 is out of range.
If non-zero, PPC14 must be within PLC41
≤ PPC14 ≤ PLC42
0415 PPC15 is out of range.
if: then:
MCC13 and MCC14 PPC15 must be within 00000 ≤ PPC15 ≤ MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PPC15 must be within 00000 ≤ PPC15 ≤ MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and PPC15 must be within 00000 ≤ PPC15 ≤ MCC14 – MCC09
MCC14 is non-zero .
MCC13 and MCC14 PPC15 must be within 00000 ≤ PPC15 ≤ MCC10 – MCC09
are both zero
0418 PPC18 is out of range.
If non-zero, PPC18 must be within PLC41
≤ PPC18 ≤ PLC42
