4–29Programming Error Codes
Publication
1771-6.5.88 – July 1997
Error Code
Description
ID = 12
0438 HPC38 is out of range.
If non-zero, HPC38 must be within HDC45
≤
HPC38
≤
HDC46
0439 HPC39 is out of range.
If non-zero, HPC39 must be within HDC41
≤
HPC39
≤
HDC42
0441
HPC41 is out of range. Valid range is 00000
≤
HPC41
≤
HDC46
0442
HPC42 is out of range. Valid range is 00000
≤
HPC42
≤
HDC42
0503 You have selected CavPress/Time execution for the Pack Profile by HPC03-B00 = 1; how-
ever, your bit pattern in MCC02 indicates that your QDC module is not configured for con-
nection of a cavity pressure sensor.
0504 You have selected closed-loop RamPress/Time execution for the Pack Profile by
HPC04-B00 = 0; however, your bit patterns in MCC02 and MCC03 indicate that the QDC
module does not have access to a connected ram (screw) pressure transducer.
0507 You have selected CavPress/Time execution for the Hold Profile by HPC03-B02 = 1; how-
ever, your bit pattern in MCC02 indicates that your QDC module is not configured for con-
nection of a cavity pressure sensor.
0508 You have selected closed-loop CavPress/Time execution for the Pack Profile by
HPC04-B01 = 0; however, your bit patterns in MCC02 and MCC03 indicate that the QDC
module does not have access to a connected cavity pressure transducer.
0512 You have selected closed-loop RamPress/Time execution for the Hold Profile by
HPC04-B02 = 0; however, your bit patterns in MCC02 and MCC03 indicate that the QDC
module does not have access to a connected ram (screw) pressure transducer.
0516 You have selected closed-loop CavPress/Time execution for the Hold Profile by
HPC04-B03 = 0; however, your bit patterns in MCC02 and MCC03 indicate that the QDC
module does not have access to a connected cavity pressure transducer.
0600 Your entire Pack/Hold Profile Command Block has been rejected because the QDC module
does not have a valid Hold Configuration Command Block on-board (SYS15-B10 = 0).
0609 Your HPC09 must be zero because PKC is invalid (SYS15-B09 = 0).
0610 Your HPC10 must be zero because PKC is invalid (SYS15-B09 = 0).
0611 Your HPC11 must be zero because PKC is invalid (SYS15-B09 = 0).
0612 Your HPC12 must be zero because PKC is invalid (SYS15-B09 = 0).
0613 Your HPC13 must be zero because PKC is invalid (SYS15-B09 = 0).
0614 Your HPC14 must be zero because PKC is invalid (SYS15-B09 = 0).
0615 Your HPC15 must be zero because PKC is invalid (SYS15-B09 = 0).
0616 Your HPC16 must be zero because PKC is invalid (SYS15-B09 = 0).
0617 Your HPC17 must be zero because PKC is invalid (SYS15-B09 = 0).
0618 Your HPC18 must be zero because PKC is invalid (SYS15-B09 = 0).
0619 Your HPC19 must be zero because PKC is invalid (SYS15-B09 = 0).
0620 Your HPC20 must be zero because PKC is invalid (SYS15-B09 = 0).
0621 Your HPC21 must be zero because PKC is invalid (SYS15-B09 = 0).
0622 Your HPC22 must be zero because PKC is invalid (SYS15-B09 = 0).
0623 Your HPC23 must be zero because PKC is invalid (SYS15-B09 = 0).
0624 Your HPC24 must be zero because PKC is invalid (SYS15-B09 = 0).
0625 Your HPC25 must be zero because PKC is invalid (SYS15-B09 = 0).
0711 HPC11 cannot be 00000 because HPC14 > 00000.
0714 HPC14 cannot be 00000 because HPC17 > 00000.
0717 HPC17 cannot be 00000 because HPC20 > 00000.
0720 HPC20 cannot be 00000 because HPC23 > 00000.
0728 HPC28 cannot be 00000.
0731 HPC31 cannot be 00000 because HPC34 > 00000.
0734 HPC34 cannot be 00000 because HPC37 > 00000.
0737 HPC37 cannot be 00000 because HPC40 > 00000.
0809 HPC09 must be 00000 when HPC11 = 00000.
