User Manual

4–27Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 11
0225
HDC25 is out of range. Valid range is 00000 ≤ HDC25 ≤ 09999
0226
HDC26 is out of range. Valid range is 00000 ≤ HDC26 ≤ 09999
0227
HDC27 is out of range. Valid range is 00000 ≤ HDC27 ≤ 09999
0228
HDC28 is out of range. Valid range is 00000 ≤ HDC28 ≤ 09999
0229
HDC29 is out of range. Valid range is 00000 ≤ HDC29 ≤ 09999
0230
HDC30 is out of range. Valid range is 00000 ≤ HDC30 ≤ 09999
0231
HDC31 is out of range. Valid range is 00000 ≤ HDC31 ≤ 09999
0232
HDC32 is out of range. Valid range is 00000 ≤ HDC32 ≤ 09999
0233
HDC33 is out of range. Valid range is 00000 ≤ HDC33 ≤ 09999
0234
HDC34 is out of range. Valid range is 00000 ≤ HDC34 ≤ 09999
0235
HDC35 is out of range. Valid range is 00000 ≤ HDC35 ≤ 09999
0236
HDC36 is out of range. Valid range is 00000 ≤ HDC36 ≤ 09999
0237
HDC37 is out of range. Valid range is 00000 ≤ HDC37 ≤ 09999
0238
HDC38 is out of range. Valid range is 00000 ≤ HDC38 ≤ 09999
0239
HDC39 is out of range. Valid range is 00000 ≤ HDC39 ≤ 09999
0240
HDC40 is out of range. Valid range is 00000 ≤ HDC40 ≤ 09999
0243
HDC43 is out of range. Valid range is 00000 ≤ HDC43 ≤ 09999
0244
HDC44 is out of range. Valid range is 00000 ≤ HDC44 ≤ 09999
0247
HDC47 is out of range. Valid range is 00000 ≤ HDC47 ≤ 09999
0248
HDC48 is out of range. Valid range is 00000 ≤ HDC48 > 09999
0249
HDC49 is out of range. Valid range is 00000 ≤ HDC49 ≤ 09999
0250
HDC50 is out of range. Valid range is 00000 ≤ HDC50 ≤ 09999
0251
HDC51 is out of range. Valid range is 00000 ≤ HDC51 ≤ 09999
0252
HDC52 is out of range. Valid range is 00000 ≤ HDC52 ≤ 09999
0253
HDC53 is out of range. Valid range is 00000 ≤ HDC53 ≤ 09999
0254
HDC54 is out of range. Valid range is 00000 ≤ HDC54 ≤ 09999
0253
HDC53 is out of range. Valid range is 00000 ≤ HDC53 ≤ 09999
0254
HDC54 is out of range. Valid range is 00000 ≤ HDC54 ≤ 09999
0343 HDC43 is equal to HDC44. They must not be equal.
0347 HDC47 is equal to HDC48. They must not be equal.
0441
HDC41 is out of range. Valid range is 00000 ≤ HDC41 < HDC42
0442
HDC42 is out of range. Valid range is HDC41 < HDC42 ≤ 09999
0445
HDC45 is out of range. Valid range is 00000 ≤ HDC45 < HDC46
0446
HDC46 is out of range. Valid range is HDC45 < HDC46 ≤ 20000
0457 HDC57 is out of range.
If non-zero, HDC57 must be within MCC17 < HDC57
≤ MCC18
0458 HDC58 is out of range.
If non-zero, HDC58 must be within MCC57 < HDC58
≤ MCC58
0502 Your bit pattern in HDC02-B02, HDC02-B01, and HDC02-B00 indicates a selected cavity
pressure control valve that is unconnected according to your entries in MCC02 and MCC04.
0506 Your bit pattern in HDC02-B06, HDC02-B05, and HDC02-B04 indicates a selected ram
(screw) pressure control valve that is unconnected
according to your entries in MCC02 and MCC04.
