User Manual

4–26 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 10
0243
PKC43 is out of range. Valid range is 00000 ≤ PKC43 ≤ 09999
0244
PKC44 is out of range. Valid range is 00000 ≤ PKC44 ≤ 09999
0247
PKC47 is out of range. Valid range is 00000 ≤ PKC47 ≤ 09999
0248
PKC48 is out of range. Valid range is 00000 ≤ PKC48 ≤ 09999
0249
PKC49 is out of range. Valid range is 00000 ≤ PKC49 ≤ 09999
0250
PKC50 is out of range. Valid range is 00000 ≤ PKC50 ≤ 09999
0251
PKC51 is out of range. Valid range is 00000 ≤ PKC51 ≤ 09999
0252
PKC52 is out of range. Valid range is 00000 ≤ PKC52 ≤ 09999
0253
PKC53 is out of range. Valid range is 00000 ≤ PKC53 ≤ 09999
0254
PKC54 is out of range. Valid range is 00000 ≤ PKC54 ≤ 09999
0343 PKC43 is equal to PKC44. They must not be equal.
0347 PKC47 is equal to PKC48. They must not be equal.
0441
PKC41 is out of range. Valid range is 00000 ≤ PKC41 < PKC42
0442
PKC42 is out of range. Valid range is PKC41 < PKC42 ≤ 09999
0445
PKC45 is out of range. Valid range is 00000 ≤ PKC45 < PKC46
0446
PKC46 is out of range. Valid range is PKC45 < PKC46 ≤ 20000
0457 PKC57 is out of range.
If non-zero, PKC57 must be within MCC17 < PKC57
≤ MCC18
0458 PKC58 is out of range.
If non-zero, PKC58 must be within MCC57 < PKC58
≤ MCC58
0502 Your bit pattern in PKC02-B02, PKC02-B01, and PKC02-B00 indicates a selected cavity
pressure control valve that is unconnected according to your entries in MCC02 and MCC04.
0506 Your bit pattern in PKC02-B06, PKC02-B05, and PKC02-B04 indicates a selected ram
(screw) pressure control valve that is unconnected according to your entries in MCC02 and
MCC04.
ID = 11 HDC – Hold Configuration Block
Error Code
Description ID = 11
0205
HDC05 is out of range. Valid range is 00000 ≤ HDC05 ≤ 09999
0206
HDC06 is out of range. Valid range is 00000 ≤ HDC06 ≤ 09999
0209
HDC09 is out of range. Valid range is 00000 ≤ HDC09 ≤ 09999
0210
HDC10 is out of range. Valid range is 00000 ≤ HDC10 ≤ 09999
0211
HDC11 is out of range. Valid range is 00000 ≤ HDC11 ≤ 09999
0212
HDC12 is out of range. Valid range is 00000 ≤ HDC12 ≤ 09999
0213
HDC13 is out of range. Valid range is 00000 ≤ HDC13 ≤ 09999
0214
HDC14 is out of range. Valid range is 00000 ≤ HDC14 ≤ 09999
0215
HDC15 is out of range. Valid range is 00000 ≤ HDC15 ≤ 09999
0216
HDC16 is out of range. Valid range is 00000 ≤ HDC16 ≤ 09999
0217
HDC17 is out of range. Valid range is 00000 ≤ HDC17 ≤ 09999
0218
HDC18 is out of range. Valid range is 00000 ≤ HDC18 ≤ 09999
0219
HDC19 is out of range. Valid range is 00000 ≤ HDC19 ≤ 09999
0220
HDC20 is out of range. Valid range is 00000 ≤ HDC20 ≤ 09999
0221
HDC21 is out of range. Valid range is 00000 ≤ HDC21 ≤ 09999
0222
HDC22 is out of range. Valid range is 00000 ≤ HDC22 ≤ 09999
0223
HDC23 is out of range. Valid range is 00000 ≤ HDC23 ≤ 09999
0224
HDC24 is out of range. Valid range is 00000 ≤ HDC24 ≤ 09999
