User Manual

1–7Abbreviated Command and Status Blocks
Publication 1771-6.5.88 – July 1997
Setpoints for Full Retract Profile
EPC33
N45:149 Segment 1 velocity
EPC34 N45:150 Segment 1 pressure
EPC35 N45:151 End of Segment 1 position
EPC36 N45:152 Segment 2 velocity
EPC37 N45:153 Segment 2 pressure
EPC38 N45:154 End of Segment 2 position
EPC39 N45:155 Segment 3 velocity
EPC40 N45:156 Segment 3 pressure
EPC41-56 N45:157-172 RFU
Critical Process Setpoints
EPC57 N45:173 Forward dwell timer preset
EPC58 N45:174 RFU
EPC59 N45:175 Fully advanced position
EPC60 N45:176 Fully retracted position
EPC61 N45:177 Clamp position to start ejector profile
EPC62 N45:178 Minimum clamp position for ejector profile
EPC63 N45:179 Maximum ejector position for clamp close profile
EPC64 N45:180 Counter preset for required ejector strokes
Word Pro-Set Address Description
Bit-mapped Control Words
ERC01 B39:4 Block ID 00000000 00010111
ERC02 B39:5 Selected valve configurations
ERC03-04 B39:6-7 RFU
Expert Response Compensation Percentage
ERC05 N45:61 ERC % minimum velocity
ERC06 N45:62 ERC % minimum pressure
ERC07 N45:63 RFU
ERC08 N45:64 RFU
Set-output Values for Unselected Valves (During Retract)
ERC09 N45:65 Output #1
ERC10 N45:66 Output #2
ERC11 N45:67 Output #3
ERC12 N45:68 Output #4
ERC13 N45:69 Output #5
ERC14 N45:70 Output #6
ERC15 N45:71 Output #7
ERC16 N45:72 Output #8
Acceleration Ramp Rates
ERC17 N45:73 Output #1
ERC18 N45:74 Output #2
ERC19 N45:75 Output #3
ERC20 N45:76 Output #4
ERC21 N45:77 Output #5
ERC22 N45:78 Output #6
ERC23 N45:79 Output #7
ERC24 N45:80 Output #8
ERC – Ejector Retract
Configuration Block
